TM18VP6 Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
EZ BEAM TM18: POLARIZED RETROREFLECTIVE
| Part | Ingress Protection | Connection Method | Response Time | Sensing Distance | Sensing Distance | Output Configuration | Cable Length | Cable Length | Operating Temperature [Max] | Operating Temperature [Min] | Light Source | Sensing Method | Voltage - Supply [Min] | Voltage - Supply [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Cable | 3 ms | 18.04 ft | 5.5 m | PNP - Dark-ON/Light-ON - Selectable | 78.74 " | 2 m | 70 °C | -40 C | Red (624nm) | Polarized Retroreflective | 10 VDC | 30 VDC |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K | Connector | 3 ms | 3.937 in | 10 cm | PNP | 70 °C | -40 C | Red (660nm) | Reflective | 10 VDC | 30 VDC | ||
 BANNER ENGINEERING | IEC IEC IP69K IP69K NEMA 6P | Connector | 3 ms | 3.937 in | 10 cm | PNP - Dark-ON/Light-ON - Selectable | 70 °C | -40 C | Infrared (870nm) | Background Suppression | 10 VDC | 30 VDC | ||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K | Connector | 3 ms | 19.685 in | 50 cm | PNP | 70 °C | -40 C | Red (660nm) | Diffuse | 10 VDC | 30 VDC | ||
BANNER ENGINEERING | IEC IEC IP69K IP69K NEMA 6P | Connector | 3 ms | 0.98 in | 25 mm | PNP - Dark-ON/Light-ON - Selectable | 70 °C | -40 C | Red (660nm) | Background Suppression | 10 VDC | 30 VDC | ||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K | Connector | 3 ms | 18.04 ft | 5.5 m | PNP | 70 °C | -40 C | Red (624nm) | Retroreflective | 10 VDC | 30 VDC | ||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K | Connector | 1.5 ms | 787.402 in | 2000 cm | PNP | 70 °C | -40 C | Through-Beam | 10 VDC | 30 VDC |
