MS27508E20B Series
Manufacturer: Conesys
Beta
⌘K
CONN RCPT FMALE 41POS CRIMP
| Part | Applications | Contact Material | Color | Shell Finish | Orientation | Number of Positions | Connector Type | Mounting Feature | Shielding | Shell Material | Ingress Protection | Primary Material | Fastening Type | Mounting Type | Insert Material | Contact Finish - Mating | Current Rating (Amps) | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Shell Size - Insert [Max] | Shell Size - Insert [Min] | Shell Size, MIL | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Conesys | Aviation Communication Systems Marine Medical Military | Copper Alloy | Olive Drab | Olive Drab Cadmium | A | 41 | Receptacle Female Sockets | Flange | Shielded | Aluminum Alloy | Environment Resistant | Metal | Bayonet Lock | Panel Mount | Thermoplastic | Gold | 7.5 A | Crimp | -65 ░C | 175 °C | 41 | 20 | G | ||
Conesys | Aviation Marine Military | Copper Alloy | Olive Drab | A | 41 | Receptacle Male Pins | Flange | Unshielded | Aluminum Alloy | Environment Resistant | Metal | Bayonet Lock | Panel Mount | Gold | Crimp | -65 ░C | 175 °C | 41 | 20 | 50 µin | 1.27 µm |
