070555 Series

Manufacturer: Molex

Catalog

CONN SHROUDED HEADER (4 SIDES) HDR 18 POS 2.54MM SOLDER RA THRU-HOLE SL TUBE

Part	Material Flammability Rating	Contact Length - Mating	Contact Length - Mating [x]	Shrouding	Number of Rows	Mounting Type	Connector Type	Insulation Height	Insulation Height	Fastening Type	Contact Finish - Mating	Insulation Material	Contact Finish - Post	Number of Positions Loaded	Features	Contact Length - Post	Contact Length - Post	Contact Shape	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Termination	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Contact Material	Style	Number of Positions	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Type	Pitch - Mating	Pitch - Mating	Insulation Color	Voltage Rating
Molex 0705550052	UL94 V-0	6.1 mm	0.24 in	Shrouded - 4 Wall	1	Through Hole Right Angle	Header	5.45 mm	0.215 in	Latch Holder	Gold	Polyester Glass Filled	Tin	All	Board Guide	0.13 in	3.3 mm	Square	15 µin	0.38 µm	Solder	-40 °C	105 ░C	Automotive General Purpose Industrial Medical	Phosphor Bronze	Board to Cable/Wire	18	74.8 Áin	1.9 Ám	Male Pin	0.1 in	2.54 mm	Black	250 VDC
Molex 0705550017	UL94 V-0	6.1 mm	0.24 in	Shrouded - 4 Wall	1	Through Hole Right Angle	Header	5.45 mm	0.215 in	Latch Holder		Polyester Glass Filled	Tin	All	Board Guide	0.13 in	3.3 mm	Square	150 Áin	3.81 Ám	Solder	-40 °C	105 ░C	Automotive General Purpose Industrial Medical	Phosphor Bronze	Board to Cable/Wire	18	150 Áin	3.81 Ám	Male Pin	0.1 in	2.54 mm	Black	250 VDC
Molex 0705550086	UL94 V-0	6.1 mm	0.24 in	Shrouded - 4 Wall	1	Through Hole Right Angle	Header	5.45 mm	0.215 in	Latch Holder	Gold	Polyester Glass Filled	Tin	All	Board Guide	0.13 in	3.3 mm	Square	30 Áin	0.76 Ám	Solder	-40 °C	105 ░C	Automotive General Purpose Industrial Medical	Phosphor Bronze	Board to Cable/Wire		74.8 Áin	1.9 Ám	Male Pin	0.1 in	2.54 mm	Black	250 VDC
Molex 0705550010	UL94 V-0	6.1 mm	0.24 in	Shrouded - 4 Wall	1	Through Hole Right Angle	Header	5.45 mm	0.215 in	Latch Holder		Polyester Glass Filled	Tin	All	Board Guide	0.13 in	3.3 mm	Square	150 Áin	3.81 Ám	Solder	-40 °C	105 ░C	Automotive General Purpose Industrial Medical	Phosphor Bronze	Board to Cable/Wire	11	150 Áin	3.81 Ám	Male Pin	0.1 in	2.54 mm	Black	250 VDC
Molex 0705550039	UL94 V-0	6.1 mm	0.24 in	Shrouded - 4 Wall	1	Through Hole Right Angle	Header	5.45 mm	0.215 in	Latch Holder	Gold	Polyester Glass Filled	Tin	All	Board Guide	0.13 in	3.3 mm	Square	15 µin	0.38 µm	Solder	-40 °C	105 ░C	Automotive General Purpose Industrial Medical	Phosphor Bronze	Board to Cable/Wire		74.8 Áin	1.9 Ám	Male Pin	0.1 in	2.54 mm	Black	250 VDC
Molex 0705550041	UL94 V-0	6.1 mm	0.24 in	Shrouded - 4 Wall	1	Through Hole Right Angle	Header	5.45 mm	0.215 in	Latch Holder	Gold	Polyester Glass Filled	Tin	All	Board Guide	0.13 in	3.3 mm	Square	15 µin	0.38 µm	Solder	-40 °C	105 ░C	Automotive General Purpose Industrial Medical	Phosphor Bronze	Board to Cable/Wire	7	74.8 Áin	1.9 Ám	Male Pin	0.1 in	2.54 mm	Black	250 VDC
Molex 0705550090	UL94 V-0	6.1 mm	0.24 in	Shrouded - 4 Wall	1	Through Hole Right Angle	Header	5.45 mm	0.215 in	Latch Holder	Gold	Polyester Glass Filled	Tin	All	Board Guide	0.13 in	3.3 mm	Square	30 Áin	0.76 Ám	Solder	-40 °C	105 ░C	Automotive General Purpose Industrial Medical	Phosphor Bronze	Board to Cable/Wire	21	74.8 Áin	1.9 Ám	Male Pin	0.1 in	2.54 mm	Black	250 VDC
Molex 0705550003	UL94 V-0	6.1 mm	0.24 in	Shrouded - 4 Wall	1	Through Hole Right Angle	Header	5.45 mm	0.215 in	Latch Holder		Polyester Glass Filled	Tin	All	Board Guide	0.13 in	3.3 mm	Square	150 Áin	3.81 Ám	Solder	-40 °C	105 ░C	Automotive General Purpose Industrial Medical	Phosphor Bronze	Board to Cable/Wire	4	150 Áin	3.81 Ám	Male Pin	0.1 in	2.54 mm	Black	250 VDC
Molex 0705550089	UL94 V-0	6.1 mm	0.24 in	Shrouded - 4 Wall	1	Through Hole Right Angle	Header	5.45 mm	0.215 in	Latch Holder	Gold	Polyester Glass Filled	Tin	All	Board Guide	0.13 in	3.3 mm	Square	30 Áin	0.76 Ám	Solder	-40 °C	105 ░C	Automotive General Purpose Industrial Medical	Phosphor Bronze	Board to Cable/Wire	20	74.8 Áin	1.9 Ám	Male Pin	0.1 in	2.54 mm	Black	250 VDC
Molex 0705550008	UL94 V-0	6.1 mm	0.24 in	Shrouded - 4 Wall	1	Through Hole Right Angle	Header	5.45 mm	0.215 in	Latch Holder		Polyester Glass Filled	Tin	All	Board Guide	0.13 in	3.3 mm	Square	150 Áin	3.81 Ám	Solder	-40 °C	105 ░C	Automotive General Purpose Industrial Medical	Phosphor Bronze	Board to Cable/Wire	9	150 Áin	3.81 Ám	Male Pin	0.1 in	2.54 mm	Black	250 VDC
