GBC04S Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
CONN HEADER VERT 4POS 2.54MM
| Part | Style | Current Rating (Amps) | Mounting Type | Contact Length - Post [x] | Contact Length - Post [x] | Overall Contact Length | Overall Contact Length | Connector Type | Number of Positions Loaded | Insulation Height | Insulation Height | Insulation Material | Fastening Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Finish - Mating | Contact Shape | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Number of Rows | Pitch - Mating | Pitch - Mating | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Finish - Post | Contact Material | Contact Length - Mating [x] | Contact Length - Mating | Shrouding | Contact Type | Number of Positions | Insulation Color | Material Flammability Rating | Contact Length - Mating [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Sullins Connector Solutions | Board to Board Cable | 3 A | Through Hole | 0.12 in | 3.05 mm | 0.45 " | 11.43 mm | Breakaway Header | All | 0.1 in | 2.54 mm | Nylon 9T Polyamide (PA9T) | Push-Pull | 10 çin | 0.25 çm | Gold | Square | -65 ░C | 150 °C | Solder | 1 | 0.1 in | 2.54 mm | 2.54 µm | 100 µin | Tin | Phosphor Bronze | 0.23 in | 5.84 mm | Unshrouded | Male Pin | 4 | Black | UL94 V-0 | |
 Sullins Connector Solutions | Board to Board Cable | 3 A | Surface Mount | Breakaway Header | All | 0.1 in | 2.54 mm | Nylon 9T Polyamide (PA9T) | Push-Pull | 10 çin | 0.25 çm | Gold | Square | -65 ░C | 150 °C | Solder | 1 | 0.1 in | 2.54 mm | 2.54 µm | 100 µin | Tin | Phosphor Bronze | 0.318 " | Unshrouded | Male Pin | 4 | Black | UL94 V-0 | 8.08 mm | |||||
 Sullins Connector Solutions | Board to Board Cable | 3 A | Surface Mount Right Angle | Breakaway Header | All | 0.14 in | 3.56 mm | Nylon 9T Polyamide (PA9T) | Push-Pull | 10 çin | 0.25 çm | Gold | Square | -65 ░C | 150 °C | Solder | 1 | 0.1 in | 2.54 mm | 2.54 µm | 100 µin | Tin | Phosphor Bronze | 0.318 " | Unshrouded | Male Pin | 4 | Black | UL94 V-0 | 8.08 mm | |||||
 Sullins Connector Solutions | Board to Board Cable | 3 A | Surface Mount Right Angle | Breakaway Header | All | 0.14 in | 3.56 mm | Nylon 9T Polyamide (PA9T) | Push-Pull | 10 çin | 0.25 çm | Gold | Square | -65 ░C | 150 °C | Solder | 1 | 0.1 in | 2.54 mm | 2.54 µm | 100 µin | Tin | Phosphor Bronze | 0.23 in | 5.84 mm | Unshrouded | Male Pin | 4 | Black | UL94 V-0 |
