83005 Series

Catalog

WIRE, HOOK UP, HI TEMP, PTFE, BLACK, 22 AWG, 1000 FT

Part	Voltage	Qualification	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Material	Jacket Color	Conductor Strand [custom]	Conductor Strand [custom]	Features	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length	Length	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Wire Gauge	Jacket (Insulation) Material	Cable Type	Ratings	Length [x]	Length [x]
Belden Inc. 83005 0101000	600 V	MIL-W-16878/4	-70 °C	200 °C	Copper Silver Coated	Black	30 AWG	7	High Temperature	0.05 "	1.27 mm	304.8 m	1000 ft	0.25 mm	0.01 in	22 AWG	Tetrafluoroethylene (TFE)	Hook-Up	UL Style 1213
Belden Inc. 83005 003100	600 V	MIL-W-16878/4	-70 °C	200 °C	Copper Silver Coated	Orange	30 AWG	7	High Temperature	0.05 "	1.27 mm			0.25 mm	0.01 in	22 AWG	Tetrafluoroethylene (TFE)	Hook-Up	UL Style 1213	100 ft	30.5 m
Belden Inc. 83005 0031000	600 V	MIL-W-16878/4	-70 °C	200 °C	Copper Silver Coated	Orange	30 AWG	7	High Temperature	0.05 "	1.27 mm	304.8 m	1000 ft	0.25 mm	0.01 in	22 AWG	Tetrafluoroethylene (TFE)	Hook-Up	UL Style 1213
Belden Inc. 83005 002100	600 V	MIL-W-16878/4	-70 °C	200 °C	Copper Silver Coated	Red	30 AWG	7	High Temperature	0.05 "	1.27 mm			0.25 mm	0.01 in	22 AWG	Tetrafluoroethylene (TFE)	Hook-Up	UL Style 1213	100 ft	30.5 m
Belden Inc. 83005 0041000	600 V	MIL-W-16878/4	-70 °C	200 °C	Copper Silver Coated	Yellow	30 AWG	7	High Temperature	0.05 "	1.27 mm	304.8 m	1000 ft	0.25 mm	0.01 in	22 AWG	Tetrafluoroethylene (TFE)	Hook-Up	UL Style 1213
Belden Inc. 83005 0021000	600 V	MIL-W-16878/4	-70 °C	200 °C	Copper Silver Coated	Red	30 AWG	7	High Temperature	0.05 "	1.27 mm	304.8 m	1000 ft	0.25 mm	0.01 in	22 AWG	Tetrafluoroethylene (TFE)	Hook-Up	UL Style 1213
Belden Inc. 83005 0091000	600 V	MIL-W-16878/4	-70 °C	200 °C	Copper Silver Coated	White	30 AWG	7	High Temperature	0.05 "	1.27 mm	304.8 m	1000 ft	0.25 mm	0.01 in	22 AWG	Tetrafluoroethylene (TFE)	Hook-Up	UL Style 1213
Belden Inc. 83005 004100	600 V	MIL-W-16878/4	-70 °C	200 °C	Copper Silver Coated	Yellow	30 AWG	7	High Temperature	0.05 "	1.27 mm			0.25 mm	0.01 in	22 AWG	Tetrafluoroethylene (TFE)	Hook-Up	UL Style 1213	100 ft	30.5 m
Belden Inc. 83005 006100	600 V	MIL-W-16878/4	-70 °C	200 °C	Copper Silver Coated	Blue	30 AWG	7	High Temperature	0.05 "	1.27 mm			0.25 mm	0.01 in	22 AWG	Tetrafluoroethylene (TFE)	Hook-Up	UL Style 1213	100 ft	30.5 m
Belden Inc. 83005 0081000	600 V	MIL-W-16878/4	-70 °C	200 °C	Copper Silver Coated	Gray	30 AWG	7	High Temperature	0.05 "	1.27 mm	304.8 m	1000 ft	0.25 mm	0.01 in	22 AWG	Tetrafluoroethylene (TFE)	Hook-Up	UL Style 1213
