PT6644 Series
Manufacturer: Texas Instruments
Beta
⌘K
DC DC CONVERTER -9V 2.5A
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Input (Max) [Max] | Package / Case | Voltage - Input (Min) [Min] | Current - Output (Max) [Max] | Applications | Efficiency | Number of Outputs | Type | Voltage - Output 1 | Mounting Type | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 85 °C | -40 °C | 21 V | 14-SIP Module | 8 V | 2.5 A | ITE (Commercial) | 84 % | 1 | Non-Isolated PoL Module | -9 V | Through Hole Right Angle | ||||||
 Texas Instruments | 85 °C | -40 °C | 21 V | 14-SMD Module | 8 V | 2.5 A | ITE (Commercial) | 84 % | 1 | Non-Isolated PoL Module | -9 V | Surface Mount | 1.71 " | 10.7 mm | 31 mm | 0.42 in | 43.4 mm | 1.22 " |
 Texas Instruments | 85 °C | -40 °C | 21 V | 14-SIP Module | 8 V | 2.5 A | ITE (Commercial) | 84 % | 1 | Non-Isolated PoL Module | -9 V | Through Hole |
