EC2-3S Series
Manufacturer: KEMET
Beta
⌘K
RELAY GENERAL PURPOSE DPDT 2A 3V
| Part | Coil Resistance | Operating Temperature [Max] | Operating Temperature [Min] | Release Time | Coil Type | Switching Voltage [Max] | Relay Type | Termination Style | Contact Material | Operate Time | Contact Rating (Current) | Coil Current | Approval Agency | Contact Form | Must Operate Voltage | Mounting Type | Load - Max Switching |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KEMET | 90 Ohms | 85 °C | -40 C | 1 ms | Latching Single Coil | 220 VDC 250 VAC | General Purpose | PC Pin | Gold Alloy Silver Alloy | 2 ms | 2 A | 33.3 mA | CSA TUV UL | DPDT (2 Form C) | 2.25 VDC | Through Hole | 60 W 125 VA |
