SWI10 Series

Manufacturer: CUI Inc.

Catalog

Catalog

AC/DC WALL MOUNT ADAPTER 12V 12W

...

Part	No Load Power Consumption	Voltage - Output	Input Type	Operating Temperature [Max]	Operating Temperature [Min]	Form	Cord Length	Cord Length	Applications	Region Utilized	Current - Output (Max) [Max]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Input Connector	Approval Agency	Polarization	Efficiency	Standard Number	Output Connector	Output Connector [custom]	Output Connector [x]	Output Connector [custom]	Power (Watts)	Voltage - Input [Max]	Voltage - Input [Min]	Weight	Weight	Output Connector [diameter]	Output Connector [z]	Output Connector [custom]
CUI Inc. SWI10B-12-EB-P7R	75 mW	12 V	Fixed Blade	40 °C	0 °C	Wall Mount	1.5 m	59 in	ITE (Commercial)	Europe	1 A	84.2 mm	41 mm	1.61 "	3.31 "	0.89 in	22.5 mm	CEE 7/16	CE	Positive Center	Level VI	62368-1	Barrel Plug R/A	1.35 mm	9.5 mm	3.5 mm	12 W	264 VAC	90 VAC
CUI Inc. SWI10-5-E-P5	75 mW	5 V	Fixed Blade	40 °C	0 °C	Wall Mount	1.5 m	59 in	ITE (Commercial)	Europe	2 A	69 mm	77.7 mm	3.06 in	2.72 in	1.13 "	28.8 mm	CEE 7/16	CB Scheme IEC	Positive Center	CoC Tier 2 Level VI	60950-1	Barrel Plug		9.5 mm		10 W	264 VAC	90 VAC	96.16 g	0.212 lb	2.1 mm 5.5 mm
CUI Inc. SWI10-5-N-P5	75 mW	5 V	Fixed Blade	40 °C	0 °C	Wall Mount	1.5 m	59 in	ITE (Commercial)	North America	2 A	69 mm	77.7 mm	3.06 in	2.72 in	1.13 "	28.8 mm	NEMA 1-15P	CSA FCC PSE UL	Positive Center	CoC Tier 2 Level VI	60950-1 C22.2 No. 60950-1	Barrel Plug		9.5 mm		10 W	264 VAC	90 VAC	90.26 g	0.199 lb	2.1 mm 5.5 mm
CUI Inc. SWI10B-5-EW-P6	75 mW	5 V	Fixed Blade	40 °C	0 °C	Wall Mount	1.5 m	59 in	ITE (Commercial)	Europe	2 A	84.2 mm	41 mm	1.61 "	3.31 "	0.89 in	22.5 mm	CEE 7/16	CE	Positive Center	Level VI	62368-1	Barrel Plug		9.5 mm		10 W	264 VAC	90 VAC			2.5 mm 5.5 mm
CUI Inc. SWI10B-12-NB-P6R	75 mW	12 V	Fixed Blade	40 °C	0 °C	Wall Mount	1.5 m	59 in	ITE (Commercial)	North America	1 A	63.1 mm	41 mm	1.61 "	2.48 in	0.89 in	22.5 mm	NEMA 1-15P	cULus FCC	Positive Center	Level VI	62368-1	Barrel Plug R/A				12 W	264 VAC	90 VAC			2.5 mm 5.5 mm	9.5 mm
CUI Inc. SWI10B-12-EB-P6	75 mW	12 V	Fixed Blade	40 °C	0 °C	Wall Mount	1.5 m	59 in	ITE (Commercial)	Europe	1 A	84.2 mm	41 mm	1.61 "	3.31 "	0.89 in	22.5 mm	CEE 7/16	CE	Positive Center	Level VI	62368-1	Barrel Plug		9.5 mm		12 W	264 VAC	90 VAC			2.5 mm 5.5 mm
CUI Inc. SWI10B-12-NB-P5R	75 mW	12 V	Fixed Blade	40 °C	0 °C	Wall Mount	1.5 m	59 in	ITE (Commercial)	North America	1 A	63.1 mm	41 mm	1.61 "	2.48 in	0.89 in	22.5 mm	NEMA 1-15P	cULus FCC	Positive Center	Level VI	62368-1	Barrel Plug R/A	2.1 mm		5.5 mm	12 W	264 VAC	90 VAC					9.5 mm
CUI Inc. SWI10B-5-EW-MUB	75 mW	5 V	Fixed Blade	40 °C	0 °C	Wall Mount	1.5 m	59 in	ITE (Commercial)	Europe	2 A	84.2 mm	41 mm	1.61 "	3.31 "	0.89 in	22.5 mm	CEE 7/16	CE		Level VI	62368-1	USB Micro				10 W	264 VAC	90 VAC
CUI Inc. SWI10B-12-EW-MUB	75 mW	12 V	Fixed Blade	40 °C	0 °C	Wall Mount	1.5 m	59 in	ITE (Commercial)	Europe	1 A	84.2 mm	41 mm	1.61 "	3.31 "	0.89 in	22.5 mm	CEE 7/16	CE		Level VI	62368-1	USB Micro				12 W	264 VAC	90 VAC
CUI Inc. SWI10-5-N-P7R	75 mW	5 V	Fixed Blade	40 °C	0 °C	Wall Mount	1.5 m	59 in	ITE (Commercial)	North America	2 A	69 mm	77.7 mm	3.06 in	2.72 in	1.13 "	28.8 mm	NEMA 1-15P	CSA FCC PSE UL	Positive Center	CoC Tier 2 Level VI	60950-1 C22.2 No. 60950-1	Barrel Plug R/A				10 W	264 VAC	90 VAC	90.26 g	0.199 lb	1.3 mm 3.5 mm		9.5 mm
