SC4509 Series
Manufacturer: Semtech Corporation
Beta
⌘K
IC LED DRVR RGLTR DIM 30MA 8MLPD
| Part | Voltage - Supply (Min) [Min] | Number of Outputs | Supplier Device Package | Dimming | Frequency | Applications | Topology | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply (Max) [Max] | Current - Output / Channel | Voltage - Output | Mounting Type | Package / Case | Type | Internal Switch(s) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Semtech Corporation | 2.7 V | 1 | 8-MLPD-W (2x2) | PWM | 1.2 MHz | Backlight | Step-Up (Boost) | 85 C | -40 ¯C | 10 V | 30 mA | 20 V | Surface Mount | 8-WFDFN Exposed Pad | DC DC Regulator |
