881806 Series

Catalog

AE C&C /500 FT /EACH ROHS COMPLIANT: YES

Part	Length	Length	Jacket Color	Conductor Material	Cable Type	Number of Conductors	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Voltage	Jacket (Insulation) Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Wire Gauge	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Strand [custom]	Conductor Strand [custom]	Ratings	Conductor Insulation	Length [x]	Length [x]
ALPHA WIRE 881806 SL002	152.4 m	500 ft	Slate	Copper Tinned	Multi-Conductor	6	7.34 mm	0.289 in	300 VDC	Poly-Vinyl Chloride (PVC)	0.813 mm	0.032 in	18 AWG	-20 ░C	90 °C	16	30 AWG	UL Style 2464	Poly-Vinyl Chloride (PVC)
ALPHA WIRE 881806 SL005			Slate	Copper Tinned	Multi-Conductor	6	7.34 mm	0.289 in	300 VDC	Poly-Vinyl Chloride (PVC)	0.813 mm	0.032 in	18 AWG	-20 ░C	90 °C	16	30 AWG	UL Style 2464	Poly-Vinyl Chloride (PVC)	100 ft	30.5 m
ALPHA WIRE 881806 SL001	304.8 m	1000 ft	Slate	Copper Tinned	Multi-Conductor	6	7.34 mm	0.289 in	300 VDC	Poly-Vinyl Chloride (PVC)	0.813 mm	0.032 in	18 AWG	-20 ░C	90 °C	16	30 AWG	UL Style 2464	Poly-Vinyl Chloride (PVC)
