043160 Series
Manufacturer: Molex
Beta
⌘K
CONN WIRE TO BOARD HDR 4 POS 7.5MM SOLDER ST TOP ENTRY THRU-HOLE BAG
| Part | Number of Positions | Mounting Type | Fastening Type | Pitch [x] | Pitch [x] | Number of Rows | Voltage Rating | Contact Finish | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Connector Type | Contact Finish Thickness [custom] | Contact Finish Thickness [custom] | Material - Insulation | Termination | Color | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 4 | Through Hole | Locking Ramp | 0.295 in | 7.5 mm | 1 | 600 V | Tin | -40 °C | 75 ░C | Brass | Header Male Blades | 1.52 µm | 60 µin | Polyamide (PA46) Nylon 4/6 Glass Filled | Solder | Black | 18 A |
 Molex | 4 | Through Hole Right Angle | Locking Ramp | 0.295 in | 7.5 mm | 1 | 600 V | Tin | -40 °C | 75 ░C | Brass | Header Male Blades | 1.52 µm | 60 µin | Polyamide (PA46) Nylon 4/6 Glass Filled | Solder | Black | 18 A |
Molex | Through Hole | Locking Ramp | 0.295 in | 7.5 mm | 1 | 600 V | Tin | -40 °C | 75 ░C | Brass | Header Male Blades | 1.52 µm | 60 µin | Polyamide (PA46) Nylon 4/6 Glass Filled | Solder | Black | 18 A | |
 Molex | 6 | Through Hole Right Angle | Locking Ramp | 0.295 in | 7.5 mm | 1 | 600 V | Tin | -40 °C | 75 ░C | Brass | Header Male Blades | 1.52 µm | 60 µin | Polyamide (PA46) Nylon 4/6 Glass Filled | Solder | Black | 18 A |
 Molex | Through Hole Right Angle | Locking Ramp | 0.295 in | 7.5 mm | 1 | 600 V | Tin | -40 °C | 75 ░C | Brass | Header Male Blades | 1.52 µm | 60 µin | Polyamide (PA46) Nylon 4/6 Glass Filled | Solder | Black | 18 A | |
 Molex | 6 | Through Hole Right Angle | Locking Ramp | 0.295 in | 7.5 mm | 1 | 600 V | Tin | -40 °C | 75 ░C | Brass | Header Male Blades | 1.52 µm | 60 µin | Polyamide (PA46) Nylon 4/6 Glass Filled | Solder | Black | 18 A |
 Molex | Through Hole Right Angle | Locking Ramp | 0.295 in | 7.5 mm | 1 | 600 V | Tin | -40 °C | 75 ░C | Brass | Header Male Blades | 1.52 µm | 60 µin | Polyamide (PA46) Nylon 4/6 Glass Filled | Solder | Black | 18 A | |
 Molex | 2 | Through Hole Right Angle | Locking Ramp | 0.295 in | 7.5 mm | 1 | 600 V | Tin | -40 °C | 75 ░C | Brass | Header Male Blades | 1.52 µm | 60 µin | Polyamide (PA46) Nylon 4/6 Glass Filled | Solder | Black | 18 A |
 Molex | Through Hole | Locking Ramp | 0.295 in | 7.5 mm | 1 | 600 V | Tin | -40 °C | 75 ░C | Brass | Header Male Blades | 1.52 µm | 60 µin | Polyamide (PA46) Nylon 4/6 Glass Filled | Solder | Black | 18 A | |
 Molex | Through Hole | Locking Ramp | 0.295 in | 7.5 mm | 1 | 600 V | Tin | -40 °C | 75 ░C | Brass | Header Male Blades | 1.52 µm | 60 µin | Polyamide (PA46) Nylon 4/6 Glass Filled | Solder | Black | 18 A |
