1393239 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RT184024
| Part | Coil Resistance | Coil Current | Release Time | Coil Type | Operating Temperature [Max] | Operating Temperature [Min] | Termination Style | Load - Max Switching [Max] | Switching Voltage [Max] | Coil Voltage | Mounting Type | Contact Material | Coil Insulation | Contact Form | Relay Type | Seal Rating | Must Operate Voltage | Approval Agency | Must Release Voltage | Contact Rating (Current) | Operate Time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | |||||||||||||||||||||
 TE Connectivity AMP Connectors | |||||||||||||||||||||
 TE Connectivity AMP Connectors | 2.3 kOhms | 10.4 mA | 8 ms | Non Latching | 85 °C | -40 C | PC Pin | 4000 VA | 400 VAC | 24 VDC | Through Hole | Gold (Au) Silver Nickel (AgNi) | Class F | SPDT (1 Form C) | General Purpose | Sealed - Flux Protection | 18 VDC | CQC CSA cURus VDE | 2.4 VDC | 10 A | 10 ms |
