842-048 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 48POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Color | Pitch | Pitch | Mounting Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Termination | Number of Rows [custom] | Contact Finish | Number of Positions | Read Out | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Card Type | Gender | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 0.1 " | 2.54 mm | Through Hole | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 24 | 125 °C | -40 C | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 2 | Gold | 48 | Dual | Cantilever | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Female | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 0.1 " | 2.54 mm | Through Hole | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 24 | 125 °C | -40 C | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 2 | Gold | 48 | Dual | Cantilever | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Female | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | 0.1 " | 2.54 mm | Through Hole | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 48 | 125 °C | -40 C | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Gold | 48 | Single | Cantilever | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Female | 1 | 1 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 0.1 " | 2.54 mm | Right Angle Through Hole | Flush Mount M3 Threaded Insert Top Opening | 24 | 125 °C | -40 C | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 2 | Gold | 48 | Dual | Cantilever | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Female | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 0.1 " | 2.54 mm | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | 24 | 125 °C | -40 C | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 2 | Gold | 48 | Dual | Cantilever | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Female | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 0.1 " | 2.54 mm | Through Hole | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 24 | 125 °C | -40 C | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | 2 | Gold | 48 | Dual | Cantilever | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Female | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | 0.1 " | 2.54 mm | Through Hole | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 48 | 125 °C | -40 C | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Gold | 48 | Single | Cantilever | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Female | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | 0.1 " | 2.54 mm | Through Hole | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 48 | 125 °C | -40 C | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Gold | 48 | Single | Cantilever | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Female | 1 | 1 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 0.1 " | 2.54 mm | Board Edge Straddle Mount | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 24 | 125 °C | -40 C | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 2 | Gold | 48 | Dual | Cantilever | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Female | Card Extender | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Green | 0.1 " | 2.54 mm | Through Hole | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 24 | 125 °C | -40 C | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | 2 | Gold | 48 | Dual | Cantilever | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Female |
