LCMD Series

Terminals Copper Comp Metric Lug, 2 Hole, 2

Manufacturer: Panduit Corp

Catalog

Terminals Copper Comp Metric Lug, 2 Hole, 2

Catalog

Terminals Copper Comp Metric Lug, 2 Hole, 2

Part	Terminal Style	Terminal Type	Mounting Type	Diameter - Barrel ID [diameter]	Diameter - Barrel ID [diameter]	Diameter - Barrel OD [diameter]	Diameter - Barrel OD [diameter]	Insulation	Tab Thickness	Tab Thickness	Width - Outer Edges [y]	Width - Outer Edges [y]	Wire Gauge	Contact Material	Contact Finish	Termination	Stud/Tab Size	Diameter - Ring ID [diameter]	Diameter - Ring ID [diameter]	Length - Overall [x]	Length - Overall [x]	Length - Overall	Length - Overall	Diameter - Ring ID [diameter]	Width - Outer Edges	Width - Outer Edges [x]	Width - Outer Edges [x]	Tab Thickness [custom]
Panduit Corp LCMD630-16-1	Two Stud Holes	Ring Tubular	Free Hanging (In-Line)	1.358 in	34.49 mm	1.732 "	43.99 mm	Non-Insulated	0.37 in	9.4 mm	2.48 in	62.99 mm	630 mm²	Copper	Tin	Barrel Crimp	M16 Stud	0.709 "	18.01 mm	175.49 mm	6.909 "
Panduit Corp LCMD10-6CD-Q	Two Stud Holes	Ring Tubular	Free Hanging (In-Line)	0.177 in	4.5 mm	0.244 in	6.2 mm	Non-Insulated	0.047 in	1.19 mm	0.433 in	11 mm	10 mm˛	Copper	Tin	Barrel Crimp	M6 Stud					55.8 mm	2.197 in
Panduit Corp LCMD630-14-1	Two Stud Holes	Ring Tubular	Free Hanging (In-Line)	1.358 in	34.49 mm	1.732 "	43.99 mm	Non-Insulated	0.37 in	9.4 mm	2.48 in	62.99 mm	630 mm²	Copper	Tin	Barrel Crimp	M14 Stud		0.63 in	175.49 mm	6.909 "			16 mm
Panduit Corp LCMD400-00-5	No Stud Hole	Ring Tubular	Free Hanging (In-Line)	1.063 in	27 mm	1.358 "	34.49 mm	Non-Insulated	0.295 in	7.49 mm	1.949 in		400 mm²	Copper	Tin	Barrel Crimp				151.51 mm	5.965 in				49.5 mm
Panduit Corp LCMD25-10-Q	Two Stud Holes	Ring Tubular	Free Hanging (In-Line)	0.272 in	6.91 mm	0.346 "	8.79 mm	Non-Insulated	0.059 in	1.5 mm	0.61 in	15.49 mm	25 mm²	Copper	Tin	Barrel Crimp	M10 Stud			81.51 mm	3.209 in
Panduit Corp LCMD95-00-X	No Stud Hole	Ring Tubular	Free Hanging (In-Line)	0.531 in	13.49 mm	0.65 in	16.51 mm	Non-Insulated	0.114 in	2.9 mm	0.965 in	24.51 mm	95 mm²	Copper	Tin	Barrel Crimp				105 mm	4.134 in
Panduit Corp LCMD150-10CD-X	Two Stud Holes	Ring Tubular	Free Hanging (In-Line)	0.65 "	16.51 mm	0.827 in	21.01 mm	Non-Insulated	0.175 in	4.45 mm			150 mm²	Copper	Tin	Barrel Crimp	M10 Stud			95.5 mm	3.76 in					30.51 mm	1.201 in
Panduit Corp LCMDX300-12-5	Two Stud Holes	Ring Tubular	Free Hanging (In-Line)	1.031 in	26.19 mm	1.299 in	32.99 mm	Non-Insulated		6.71 mm	1.89 in	48.01 mm	300 mm²	Copper	Tin	Barrel Crimp	M12 Stud		0.551 "	151.51 mm	5.965 in			14 mm				0.264 in
Panduit Corp LCMD300-12-5	Two Stud Holes	Ring Tubular	Free Hanging (In-Line)	0.925 in	23.5 mm	1.142 in	29.01 mm	Non-Insulated	0.213 in	5.4 mm	1.673 in	42.49 mm	300 mm²	Copper	Tin	Barrel Crimp	M12 Stud		0.551 "	139 mm	5.472 in			14 mm
Panduit Corp LCMD6-5CD-Q	Two Stud Holes	Ring Tubular	Free Hanging (In-Line)	0.15 in	3.81 mm	0.217 in	5.51 mm	Non-Insulated	0.046 in	1.17 mm			6 mm²	Copper	Tin	Barrel Crimp	M5 Stud			52.5 mm	2.067 "					10 mm	0.394 in
