SMP STRAIGHT PLUG PCB
| Part | Body Finish | Fastening Type | Mounting Type | Mating Cycles | Impedance | Center Contact Material | Contact Termination | Features | Body Material | Connector Type | Number of Ports | Center Contact Plating | Voltage Rating | Operating Temperature (Max) | Operating Temperature (Min) | Dielectric Material | Connector Style | Frequency - Max | Housing Color | Shield Termination | Connector Plug Diameter | Contact Finish | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Rosenberger | Gold | Snap-On | Through Hole | 500 cycles | 50 Ohm | Brass | Solder | Smooth Bore | Brass | Male Pin Plug | 1 | Gold | 335 V | 155 °C | -65 °C | Polyetheretherketone (PEEK) | SMP | 26.5 GHz | Gold | Solder | |||
Rosenberger | Gold | Threaded | 30° Angle Surface Mount | 3000 cycles | 50 Ohm | Beryllium Copper | Mounting Hardware | Beryllium Copper | Female Socket Jack | 1 | Gold | 150 VDC | 85 °C | -40 °C | Polyetheretherketone (PEEK) | 90 GHz | Gold | Screw | 1.35 mm | ||||
Rosenberger | Gold | Snap-On | Surface Mount | 500 cycles | 50 Ohm | Beryllium Copper | Solder | Brass | Female Socket Jack | 1 | Gold | 335 V | 155 °C | -55 °C | Polytetrafluoroethylene (PTFE) | MCX | 6000 MHz | Gold | Solder | ||||
Rosenberger | Gold | Cap Free Hanging | 50 Ohm | Full Detent | Beryllium Copper | Male Pin Plug | Polytetrafluoroethylene (PTFE) | Mini SMP | 40 Gbps | Gold | Beryllium Copper | ||||||||||||
 Rosenberger | Gold | Snap-On | Surface Mount | 500 cycles | 50 Ohm | Brass | Solder | Limited Detent | Brass | Male Pin Plug | 1 | Gold | 335 V | 155 °C | -65 °C | Liquid Crystal Polymer (LCP) | SMP | 26.5 GHz | Gold | Solder | |||
Rosenberger | Gold | Cap Free Hanging | 50 Ohm | Brass | Male Pin Plug | Polytetrafluoroethylene (PTFE) | SMA | 12.4 GHz | Gold | Brass | |||||||||||||
Rosenberger | Gold | Cap Free Hanging | 50 Ohm | Beryllium Copper | Female Socket Jack | Polytetrafluoroethylene (PTFE) | SMP | 18 GHz | Gold | Beryllium Copper | |||||||||||||
Rosenberger | Gold | Snap-On | Surface Mount | 1000 cycles | 50 Ohm | Brass | Solder | Catcher's Mitt | Brass | Male Pin Plug | 1 | Gold | 335 V | 155 °C | -65 °C | Liquid Crystal Polymer (LCP) | Longwipe SMP | 6000 MHz | Gold | Solder | |||
Rosenberger | Gold | Snap-On | Board Edge Cutout Surface Mount | 1000 cycles | 50 Ohm | Brass | Solder | Smooth Bore | Brass | Male Pin Plug | 1 | Gold | 335 V | 155 °C | -65 °C | Polytetrafluoroethylene (PTFE) | SMP | 26.5 GHz | Gold | Solder | |||
Rosenberger | Gold | Cap Free Hanging | 50 Ohm | Beryllium Copper | Female Socket Jack | Polytetrafluoroethylene (PTFE) | Mini SMP | 40 Gbps | Gold | Beryllium Copper |
