DPD-09 Series
Manufacturer: Adam Tech
Beta
⌘K
D-SUB DUALPORT CONNECTORS CONN D-TYPE PLUG/RCPT 9P RA SLDR
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Contact Material | Voltage Rating | Contact Form | Color | Contact Finish | Termination | Shell Size, Connector Layout | Flange Feature | Flange Feature | Connector Style | Number of Rows [custom] | Mounting Type | Number of Positions | Features | Current Rating (Amps) | Shell Material, Finish | Backset Spacing | Backset Spacing | Material Flammability Rating | Connector Type | Contact Finish Thickness | Contact Finish Thickness | Contact Finish Thickness | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | -55 C | 85 °C | Polybutylene Terephthalate (PBT) | Copper Alloy | 250 VAC | Stamped | Black | Gold | Solder | 1 | Housing/Shell | 4-40 | D-Type - Stacked | 2 | Right Angle Through Hole | 9 | Board Lock Grounding Indents Mounting Brackets | 3 A | Nickel Plated Steel | 8.08 mm | 0.318 " | UL94 V-0 | Plug Male Pins Receptacle Female Sockets | ||||
 Adam Tech | -55 C | 85 °C | Polybutylene Terephthalate (PBT) | Copper Alloy | 250 VAC | Stamped | Black | Gold | Solder | 1 | Housing/Shell | 4-40 | D-Type - Stacked | 2 | Right Angle Through Hole | 9 | Grounding Indents Mounting Brackets | 3 A | Nickel Plated Steel | 8.08 mm | 0.318 " | UL94 V-0 | Plug Male Pins Receptacle Female Sockets | ||||
 Adam Tech | -55 C | 85 °C | Polybutylene Terephthalate (PBT) | Copper Alloy | 250 VAC | Stamped | Black | Gold | Solder | 1 | Housing/Shell | 4-40 | D-Type - Stacked | 2 | Right Angle Through Hole | 9 | Mounting Brackets | 3 A | Nickel Plated Steel | 8.08 mm | 0.318 " | UL94 V-0 | Receptacle Female Sockets | Flash | |||
 Adam Tech | -55 C | 85 °C | Polybutylene Terephthalate (PBT) | Copper Alloy | 250 VAC | Stamped | Black | Gold | Solder | 1 | Housing/Shell | 4-40 | D-Type - Stacked | 2 | Right Angle Through Hole | 9 | Board Lock Mounting Brackets | 3 A | Nickel Plated Steel | 8.08 mm | 0.318 " | UL94 V-0 | Receptacle Female Sockets | ||||
 Adam Tech | -55 C | 85 °C | Polybutylene Terephthalate (PBT) | Copper Alloy | 250 VAC | Stamped | Black | Gold | Solder | 1 | 4-40 | D-Sub - Stacked | 2 | Right Angle Through Hole | 9 | Board Lock Grounding Indents Mounting Brackets | 3 A | Nickel Plated Steel | 8.08 mm | 0.318 " | UL94 V-0 | Plug Male Pins Receptacle Female Sockets | 5 µin | 0.127 µm | Signal | ||
 Adam Tech | -65 ░C | 125 °C | Polybutylene Terephthalate (PBT) | Phosphor Bronze | 250 VAC | Stamped | Black | Gold | Solder | 1 | Housing/Shell (Unthreaded) | D-Type - Stacked | 2 | Right Angle Through Hole | 9 | Mounting Brackets | 5 A | Steel Zinc Plated | 8.08 mm | 0.318 " | UL94 V-0 | Receptacle Female Sockets | Flash | ||||
 Adam Tech | -55 C | 85 °C | Polybutylene Terephthalate (PBT) | Copper Alloy | 250 VAC | Stamped | Black | Gold | Solder | 1 | Housing/Shell | 4-40 | D-Type - Stacked | 2 | Right Angle Through Hole | 9 | Board Lock Grounding Indents Mounting Brackets | 3 A | Nickel Plated Steel | 8.08 mm | 0.318 " | UL94 V-0 | Plug Male Pins |
