895-041 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 41POS 0.100
...
| Part | Termination Rows | Material - Insulation | Contact Material | Termination | Card Thickness [Max] | Card Thickness [Min] | Read Out | Number of Positions/Bay/Row | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Card Type | Number of Rows | Gender | Contact Finish | Pitch | Pitch | Number of Positions | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Cantilever | 125 °C | -40 C | Black | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Female | Gold | 0.1 " | 2.54 mm | 41 | Right Angle Through Hole |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Cantilever | 125 °C | -40 C | Black | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Female | Gold | 0.1 " | 2.54 mm | 41 | Through Hole |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Cantilever | 125 °C | -40 C | Black | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Female | Gold | 0.1 " | 2.54 mm | 41 | Through Hole | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Cantilever | 125 °C | -40 C | Black | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Female | Gold | 0.1 " | 2.54 mm | 41 | Through Hole |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Cantilever | 125 °C | -40 C | Black | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Female | Gold | 0.1 " | 2.54 mm | 41 | Right Angle Through Hole |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Cantilever | 125 °C | -40 C | Black | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Female | Gold | 0.1 " | 2.54 mm | 41 | Right Angle Through Hole |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Cantilever | 125 °C | -40 C | Black | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Female | Gold | 0.1 " | 2.54 mm | 41 | Through Hole | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Cantilever | 125 °C | -40 C | Black | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Female | Gold | 0.1 " | 2.54 mm | 41 | Through Hole | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Cantilever | 125 °C | -40 C | Black | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Female | Gold | 0.1 " | 2.54 mm | 41 | Through Hole | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Cantilever | 125 °C | -40 C | Black | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Female | Gold | 0.1 " | 2.54 mm | 41 | Through Hole |
