SRP1045 Series
Manufacturer: Bourns Inc.
Beta
⌘K
FIXED IND 2.2UH 9.5A 8.7MOHM SMD
| Part | Material - Core | DC Resistance (DCR) [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Shielding | Current Rating (Amps) | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Height - Seated (Max) [Max] | Height - Seated (Max) | Current - Saturation (Isat) | Tolerance | Mounting Type | Package / Case | Type | Inductance | Inductance Frequency - Test |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | Ferrite | 8.7 mOhm | -55 C | 150 °C | Shielded | 9.5 A | 0.368 in | 0.433 in | 11 mm | 9.35 mm | 0.189 " | 4.8 mm | 10 A | 20 % | Surface Mount | Nonstandard | Drum Core Wirewound | 2.2 µH | 100 kHz |
