SRR1050HA Series

Catalog

INDUCTOR POWER SHIELDED WIREWOUND 180UH 30% 100KHZ FERRITE 1A 0.42OHM DCR AUTOMOTIVE AEC-Q200 T/R

Part	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Frequency - Self Resonant	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Current Rating (Amps)	Shielding	Mounting Type	Current - Saturation (Isat)	Inductance Frequency - Test	Type	Package / Case	Inductance	Tolerance	Ratings	Material - Core	Operating Temperature [Min]	Operating Temperature [Max]	DC Resistance (DCR)	DC Resistance (DCR) [Max]
Bourns Inc. SRR1050HA-181Y	0.201 in	5.1 mm	3.4 MHz	10 mm	10.2 mm	0.402 in	0.394 in	1 A	Shielded	Surface Mount	1.04 A	100 kHz	Drum Core Wirewound	Nonstandard	180 µH	30 %	AEC-Q200	Ferrite	-55 C	150 °C	420 mOhm
Bourns Inc. SRR1050HA-390Y	0.201 in	5.1 mm	6.8 MHz	10 mm	10.2 mm	0.402 in	0.394 in	2.25 A	Shielded	Surface Mount	2.3 A	100 kHz	Drum Core Wirewound	Nonstandard	39 µH	30 %	AEC-Q200	Ferrite	-55 C	150 °C	106 mOhm
Bourns Inc. SRR1050HA-2R2Y	0.201 in	5.1 mm	53 MHz	10 mm	10.2 mm	0.402 in	0.394 in	7.2 A	Shielded	Surface Mount	8.2 A	100 kHz	Drum Core Wirewound	Nonstandard	2.2 µH	30 %	AEC-Q200	Ferrite	-55 C	150 °C		9 mOhm
Bourns Inc. SRR1050HA-120Y	0.201 in	5.1 mm	15 MHz	10 mm	10.2 mm	0.402 in	0.394 in	3.8 A	Shielded	Surface Mount	4 A	100 kHz	Drum Core Wirewound	Nonstandard	12 µH	30 %	AEC-Q200	Ferrite	-55 C	150 °C		35 mOhm
Bourns Inc. SRR1050HA-331Y	0.201 in	5.1 mm	2 MHz	10 mm	10.2 mm	0.402 in	0.394 in	0.73 A	Shielded	Surface Mount	750 mA	100 kHz	Drum Core Wirewound	Nonstandard	330 µH	30 %	AEC-Q200	Ferrite	-55 C	150 °C		815 mOhm
Bourns Inc. SRR1050HA-R68Y	0.201 in	5.1 mm	110 MHz	10 mm	10.2 mm	0.402 in	0.394 in	9.5 A	Shielded	Surface Mount	13.5 A	100 kHz	Drum Core Wirewound	Nonstandard	0.68 µH	30 %	AEC-Q200	Ferrite	-55 C	150 °C		5.5 mOhm
