845-025 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 25POS 0.100
...
| Part | Number of Positions/Bay/Row [custom] | Number of Rows | Contact Finish | Gender | Color | Contact Finish Thickness | Contact Finish Thickness | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Card Type | Mounting Type | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Termination Rows | Flange Feature | Contact Material | Pitch [x] | Pitch [x] | Termination | Read Out | Flange Feature [diameter] | Flange Feature [diameter] | Flange Feature | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 25 | 1 | Gold | Female | Green | 10 Áin | 0.25 Ám | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Cantilever | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | M3 Threaded Insert Top Mount Opening | Copper Alloy | 2.54 mm | 0.1 in | Solder | Single | ||||
 EDAC Inc. | 25 | 1 | Gold | Female | Green | 10 Áin | 0.25 Ám | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Cantilever | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | M3 Threaded Insert Top Mount Opening | Copper Alloy | 2.54 mm | 0.1 in | Wire Wrap | Single | ||||
 EDAC Inc. | 25 | 1 | Gold | Female | Green | 10 Áin | 0.25 Ám | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Cantilever | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | M3 Threaded Insert Top Mount Opening | Copper Alloy | 2.54 mm | 0.1 in | Wire Wrap | Single | ||||
 EDAC Inc. | 25 | 1 | Gold | Female | Green | 10 Áin | 0.25 Ám | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Cantilever | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | Top Mount Opening Unthreaded | Copper Alloy | 2.54 mm | 0.1 in | Solder | Single | 0.156 in | 3.96 mm | ||
 EDAC Inc. | 25 | 1 | Gold | Female | Green | 10 Áin | 0.25 Ám | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Cantilever | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | Side Mount Opening Unthreaded | Copper Alloy | 2.54 mm | 0.1 in | Wire Wrap | Single | 3.25 mm | 0.128 in | ||
 EDAC Inc. | 25 | 1 | Gold | Female | Green | 10 Áin | 0.25 Ám | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Cantilever | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | Floating Bobbin Flush Mount | Copper Alloy | 2.54 mm | 0.1 in | Solder | Single | 0.116 in | 2.95 mm | ||
 EDAC Inc. | 25 | 1 | Gold | Female | Green | 10 Áin | 0.25 Ám | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Cantilever | Non Specified - Single Edge | Through Hole Right Angle | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | 2.54 mm | 0.1 in | Solder | Single | ||||
 EDAC Inc. | 25 | 1 | Gold | Female | Green | 10 Áin | 0.25 Ám | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Cantilever | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | M3 Threaded Insert Top Mount Opening | Copper Alloy | 2.54 mm | 0.1 in | Solder | Single | ||||
 EDAC Inc. | 25 | 1 | Gold | Female | Green | 10 Áin | 0.25 Ám | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Cantilever | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | Side Mount Opening Unthreaded | Copper Alloy | 2.54 mm | 0.1 in | Solder | Single | 3.25 mm | 0.128 in | ||
 EDAC Inc. | 25 | 1 | Gold | Female | Green | 10 Áin | 0.25 Ám | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Cantilever | Non Specified - Single Edge | Through Hole | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 1 | Floating Bobbin Flush Mount | Copper Alloy | 2.54 mm | 0.1 in | Solder | Single | 0.116 in | 2.95 mm |
