501568 Series

Manufacturer: Molex

Catalog

1.00MM PITCH, PICO-CLASP PCB HEADER, SINGLE ROW, RIGHT-ANGLE, SURFACE MOUNT, TIN PLATED, INNER POSITIVE LOCK, 11 CIRCUITS, RED

Part	Applications	Insulation Material	Contact Type	Insulation Height [z]	Insulation Height [z]	Number of Positions	Features	Shrouding	Contact Finish - Post	Contact Shape	Style	Termination	Mounting Type	Number of Positions Loaded	Material Flammability Rating	Connector Type	Fastening Type	Insulation Color	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Pitch - Mating	Pitch - Mating	Number of Rows	Contact Material	Insulation Height
Molex 5015681127
Molex 5015681407	General Purpose	Nylon Polyamide (PA)	Male Pin	0.185 in	4.7 mm	14	Solder Retention	Shrouded - 4 Wall	Tin	Square	Board to Cable/Wire	Solder	Right Angle Surface Mount	All	UL94 V-0	Header	Latch Holder	Natural	1.02 µm	40 µin	1 mm	0.039 in	1	Phosphor Bronze
Molex 5015681507	General Purpose	Nylon Polyamide (PA)	Male Pin	0.185 in	4.7 mm	15	Solder Retention	Shrouded - 4 Wall	Tin	Square	Board to Cable/Wire	Solder	Right Angle Surface Mount	All	UL94 V-0	Header	Latch Holder	Natural	1.02 µm	40 µin	1 mm	0.039 in	1	Phosphor Bronze
Molex 5015680807	General Purpose	Nylon Polyamide (PA)	Male Pin	0.185 in	4.7 mm	8	Solder Retention	Shrouded - 4 Wall	Tin	Square	Board to Cable/Wire	Solder	Right Angle Surface Mount	All	UL94 V-0	Header	Latch Holder	Natural	1.02 µm	40 µin	1 mm	0.039 in	1	Phosphor Bronze
Molex 5015680607	General Purpose	Nylon Polyamide (PA)	Male Pin	0.185 in	4.7 mm	6	Solder Retention	Shrouded - 4 Wall	Tin	Square	Board to Cable/Wire	Solder	Right Angle Surface Mount	All	UL94 V-0	Header	Latch Holder	Natural	1.02 µm	40 µin	1 mm	0.039 in	1	Phosphor Bronze
Molex 5015681107		Nylon Polyamide (PA)	Male Pin	0.185 in	4.7 mm	11	Solder Retention	Shrouded - 4 Wall	Tin	Square	Board to Cable/Wire	Solder	Right Angle Surface Mount	All	UL94 V-0	Header	Latch Holder	Natural	1.02 µm	40 µin	1 mm	0.039 in	1	Phosphor Bronze
Molex 5015680707	General Purpose	Nylon Polyamide (PA)	Male Pin	0.185 in	4.7 mm	7	Solder Retention	Shrouded - 4 Wall	Tin	Square	Board to Cable/Wire	Solder	Right Angle Surface Mount	All	UL94 V-0	Header	Latch Holder	Natural	1.02 µm	40 µin	1 mm	0.039 in	1	Phosphor Bronze
Molex 5015681307	General Purpose	Nylon Polyamide (PA)	Male Pin	0.185 in	4.7 mm	13	Solder Retention	Shrouded - 4 Wall	Tin	Square	Board to Cable/Wire	Solder	Right Angle Surface Mount	All	UL94 V-0	Header	Latch Holder	Natural	1.02 µm	40 µin	1 mm	0.039 in	1	Phosphor Bronze
Molex 5015680407		Nylon Polyamide (PA)	Male Pin	0.126 "		4	Solder Retention	Shrouded - 4 Wall	Tin	Square	Board to Cable/Wire	Solder	Right Angle Surface Mount	All	UL94 V-0	Header	Latch Holder	Natural	1.02 µm	40 µin	1 mm	0.039 in	1	Phosphor Bronze	3.2 mm
