E2E-X8 Series
Manufacturer: Omron Electronics Inc-EMC Div
Catalog
SENSOR INDUCT 8MM NPN M18 NC
...
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Indicator [custom] | Output Type | Termination Style | Sensor Type | Response Frequency | Package / Case | Ingress Protection | Sensing Distance | Sensing Distance | Shielding | Voltage - Supply [Max] | Voltage - Supply [Min] | Material - Body |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Omron Electronics Inc-EMC Div | 70 °C | -25 °C | LED | NPN-NC 3-Wire | Cable Leads | Inductive | 500 Hz | Cylinder Threaded - M18 | IP67 IP69K | 0.315 in | 8 mm | Shielded | 30 VDC | 10 VDC | Nickel-Plated Brass |
Omron Electronics Inc-EMC Div | 70 °C | -25 °C | LED | PNP-NO 3-Wire | Cable Leads | Inductive | 500 Hz | Cylinder Threaded - M18 | IP67 IP69K | 0.315 in | 8 mm | Shielded | 30 VDC | 10 VDC | Nickel-Plated Brass |
Omron Electronics Inc-EMC Div | 70 °C | -25 °C | LED | PNP-NO 3-Wire | Connector | Inductive | 500 Hz | Cylinder Threaded - M18 | IP67 IP69K | 0.315 in | 8 mm | Shielded | 30 VDC | 10 VDC | Nickel-Plated Brass |
 Omron Electronics Inc-EMC Div | 85 °C | -40 °C | LED | PNP-NC 3-Wire | Cable with Connector | Inductive | Cylinder Threaded - M12 | IP67 IP69K | 0.315 in | 8 mm | Unshielded | 30 VDC | 10 VDC | Stainless Steel | |
Omron Electronics Inc-EMC Div | 70 °C | -25 °C | LED | PNP-NO 3-Wire | Cable Leads | Inductive | 500 Hz | Cylinder Threaded - M18 | IP67 IP69K | 0.315 in | 8 mm | Shielded | 30 VDC | 10 VDC | Nickel-Plated Brass |
 Omron Electronics Inc-EMC Div | 85 °C | -40 °C | LED | PNP-NO 3-Wire | Cable Leads | Inductive | Cylinder Threaded - M12 | IP67 IP69K | 0.315 in | 8 mm | Unshielded | 30 VDC | 10 VDC | Stainless Steel | |
Omron Electronics Inc-EMC Div | 70 °C | -25 °C | LED | PNP-NO 3-Wire | Connector | Inductive | 500 Hz | Cylinder Threaded - M8 | IP67 IP69K | 0.315 in | 8 mm | Unshielded | 30 VDC | 10 VDC | Stainless Steel |
Omron Electronics Inc-EMC Div | 70 °C | -25 °C | LED | PNP-NC 3-Wire | Cable Leads | Inductive | 500 Hz | Cylinder Threaded - M18 | IP67 IP69K | 0.315 in | 8 mm | Shielded | 30 VDC | 10 VDC | Nickel-Plated Brass |
 Omron Electronics Inc-EMC Div | 70 °C | -25 °C | LED | PNP-NO 3-Wire | Cable Leads | Inductive | 500 Hz | Cylinder Threaded - M8 | IP67 IP69K | 0.315 in | 8 mm | Unshielded | 30 VDC | 10 VDC | Stainless Steel |
Omron Electronics Inc-EMC Div | 70 °C | -25 °C | LED | PNP-NO 3-Wire | Cable Leads | Inductive | 500 Hz | Cylinder Threaded - M8 | IP67 IP69K | 0.315 in | 8 mm | Unshielded | 30 VDC | 10 VDC | Stainless Steel |
