854-005 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN RCPT MALE 5P GOLD SLDR CUP
| Part | Primary Material | Operating Temperature [Max] | Operating Temperature [Min] | Color | Cable Opening | Cable Opening | Fastening Type | Mounting Type | Connector Type | Material Flammability Rating | Current Rating (Amps) | Contact Finish - Mating | Contact Material | Ingress Protection | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Voltage Rating | Applications | Shell Material | Number of Positions | Insert Material | Shell Size - Insert | Shell Finish | Features | Contact Finish Thickness - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Metal | 85 °C | -40 C | Black Silver | 0.244 in | 6.2 mm | Threaded | Free Hanging (In-Line) | Receptacle Male Pins | UL94 V-0 | 1.5 A | Gold | Copper Alloy | IP67 - Dust Tight Waterproof | 0.25 µm | 10 µin | 30 VDC | Industrial Medical | Copper Alloy | 5 | Polybutylene Terephthalate (PBT) | M8-5 | Nickel | ||
 NorComp Inc. | Metal | 85 °C | -40 C | Black Silver | Threaded | Free Hanging (In-Line) | Plug Female Sockets | UL94 V-0 | 1.5 A | Gold | Phosphor Bronze | IP67 - Dust Tight Waterproof | 0.25 µm | 10 µin | 30 VDC | Industrial Medical | Brass | 5 | Polybutylene Terephthalate (PBT) | M8-5 | Nickel | Coupling Nut Ground | |||
 NorComp Inc. | Metal | 85 °C | -40 C | Black Silver | 0.244 in | 6.2 mm | Threaded | Free Hanging (In-Line) | Receptacle Male Pins | UL94 V-0 | 1.5 A | Gold | Copper Alloy | IP67 - Dust Tight Waterproof | 30 VDC | Industrial Medical | Copper Alloy | 5 | Polybutylene Terephthalate (PBT) | M8-5 | Nickel | Flash |
