GZC06 Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
CONN HEADER SMD 12POS 2.54MM
| Part | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insulation Color | Contact Length - Mating | Contact Length - Mating | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Number of Positions | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Finish - Mating | Shrouding | Contact Type | Termination | Number of Positions Loaded | Voltage Rating | Fastening Type | Contact Finish - Post | Current Rating (Amps) | Pitch - Mating | Pitch - Mating | Mounting Type | Insulation Height | Insulation Height | Contact Shape | Insulation Material | Material Flammability Rating | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows [custom] | Style | Contact Material | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sullins Connector Solutions | 0.25 µm | 10 µin | Black | 8.08 mm | 0.318 in | 0.1 in | 2.54 mm | 12 | 2.54 µm | 100 µin | Gold | Unshrouded | Male Pin | Solder | All | 600 V | Push-Pull | Tin-Lead | 3 A | 0.1 " | 2.54 mm | Surface Mount | 0.1 in | 2.54 mm | Square | Nylon 9T Polyamide (PA9T) | UL94 V-0 | Header | -65 ░C | 125 °C | 2 | Board to Board Cable | Phosphor Bronze | |
 Sullins Connector Solutions | 0.25 µm | 10 µin | Black | 5.84 mm | 0.23 in | 6 | 2.54 µm | 100 µin | Gold | Unshrouded | Male Pin | Solder | All | 600 V | Push-Pull | Tin-Lead | 3 A | 0.1 " | 2.54 mm | Surface Mount | 0.1 in | 2.54 mm | Square | Nylon 9T Polyamide (PA9T) | UL94 V-0 | Header | -65 ░C | 125 °C | Board to Board Cable | Phosphor Bronze | 1 | |||
 Sullins Connector Solutions | 0.25 µm | 10 µin | Black | 5.84 mm | 0.23 in | 6 | 2.54 µm | 100 µin | Gold | Unshrouded | Male Pin | Solder | All | 600 V | Push-Pull | Tin-Lead | 3 A | 0.1 " | 2.54 mm | Right Angle Surface Mount | 0.14 in | 3.56 mm | Square | Nylon 9T Polyamide (PA9T) | UL94 V-0 | Header | -65 ░C | 125 °C | Board to Board Cable | Phosphor Bronze | 1 | |||
 Sullins Connector Solutions | 0.25 µm | 10 µin | Black | 5.84 mm | 0.23 in | 0.1 in | 2.54 mm | 12 | 2.54 µm | 100 µin | Gold | Unshrouded | Male Pin | Solder | All | 600 V | Push-Pull | Tin-Lead | 3 A | 0.1 " | 2.54 mm | Surface Mount | 0.1 in | 2.54 mm | Square | Nylon 9T Polyamide (PA9T) | UL94 V-0 | Header | -65 ░C | 125 °C | 2 | Board to Board Cable | Phosphor Bronze |
