L313 Series
Manufacturer: Sensata-Crydom
Beta
⌘K
L SERIES POWER MODULE
| Part | Structure | Current - Non Rep. Surge 50, 60Hz (Itsm) | Voltage - Gate Trigger (Vgt) (Max) [Max] | Mounting Type | Number of SCRs, Diodes [custom] | Number of SCRs, Diodes [custom] | Voltage - Off State | Package / Case | Current - Gate Trigger (Igt) (Max) [Max] | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | Bridge Single Phase - SCRs/Diodes (Layout 1) | 2250 A | 2.5 V | Chassis Mount | 2 | 2 | 800 V | Module | 100 mA | -40 C | 125 °C |
