SFV21R Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN FPC BOTTOM 21POS 0.5MM R/A
| Part | Housing Color | Actuator Color | Mating Cycles | Locking Feature | Current Rating (Amps) | Height Above Board [z] | Height Above Board [z] | Operating Temperature [Min] | Operating Temperature [Max] | Connector/Contact Type | Termination | Flat Flex Type | Material Flammability Rating | Pitch | Pitch | Contact Material | Cable End Type | Number of Positions | Voltage Rating | Contact Finish | Mounting Type | Housing Material | Actuator Material | FFC, FCB Thickness | Features | FFC, FCB Thickness [custom] | FFC, FCB Thickness [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Black | Black | 20 | Flip Lock Slide Lock | 0.5 A | 0.071 in | 1.8 mm | -55 C | 105 ░C | Contacts Bottom | Solder | FPC | UL94 V-0 | 0.02 " | 0.5 mm | Phosphor Bronze | Notched Tabbed | 21 | 50 V | Gold | Right Angle Surface Mount | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | 0.3 mm | Solder Retention Zero Insertion Force (ZIF) | ||
 Amphenol ICC (FCI) | Black | Brown | 20 | Slide Lock | 0.5 A | 0.071 in | 1.8 mm | -55 C | 105 ░C | Contacts Top | Solder | FFC FPC | UL94 V-0 | 0.02 " | 0.5 mm | Phosphor Bronze | Straight Tapered | 21 | 50 V | Tin Alloy | Right Angle Surface Mount | Glass Filled Nylon Polyamide (PA) | Polyphenylene Sulfide (PPS) Glass Filled | Solder Retention Zero Insertion Force (ZIF) | 0.3 mm | 0.33 mm | |
 Amphenol ICC (FCI) | Black | Brown | 20 | Slide Lock | 0.5 A | 0.071 in | 1.8 mm | -55 C | 105 ░C | Contacts Top | Solder | FPC | UL94 V-0 | 0.02 " | 0.5 mm | Phosphor Bronze | Notched | 21 | 50 V | Tin | Right Angle Surface Mount | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | 0.3 mm | 0.33 mm | ||
 Amphenol ICC (FCI) | Black | Beige | 20 | Slide Lock | 0.5 A | 0.071 in | 1.8 mm | -55 C | 105 ░C | Contacts Bottom | Solder | FFC FPC | UL94 V-0 | 0.02 " | 0.5 mm | Phosphor Bronze | Tapered | 21 | 50 V | Tin | Right Angle Surface Mount | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | 0.3 mm | |||
 Amphenol ICC (FCI) | Black | Brown | 20 | Slide Lock | 0.5 A | 0.071 in | 1.8 mm | -55 C | 105 ░C | Contacts Top | Solder | FFC FPC | UL94 V-0 | 0.02 " | 0.5 mm | Phosphor Bronze | Tapered | 21 | 50 V | Gold | Right Angle Surface Mount | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | 0.33 mm | |||
 Amphenol ICC (FCI) | Black | Black | 20 | Slide Lock | 0.5 A | 0.071 in | 1.8 mm | -55 C | 105 ░C | Contacts Bottom | Solder | FPC | UL94 V-0 | 0.02 " | 0.5 mm | Phosphor Bronze | Straight Tapered | 21 | 50 V | Tin | Right Angle Surface Mount | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | 0.3 mm | 0.33 mm | ||
 Amphenol ICC (FCI) | Black | Brown | Slide Lock | 0.5 A | 0.071 in | 1.8 mm | -55 C | 105 ░C | Contacts Top | Solder | FFC FPC | UL94 V-0 | 0.02 " | 0.5 mm | Phosphor Bronze | Straight Tapered | 21 | 50 V | Tin | Right Angle Surface Mount | Glass Filled Nylon Polyamide (PA) | Polyphenylene Sulfide (PPS) Glass Filled | Solder Retention Zero Insertion Force (ZIF) | 0.3 mm | 0.33 mm |
