3404.2417 Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
FUSE BRD MNT 1.25A 277VAC 250VDC
| Part | Melting I˛t | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating - AC | Voltage Rating - DC | Current Rating (Amps) | Breaking Capacity @ Rated Voltage | Package / Case | Melting I²t | Approval Agency | Response Time | Mounting Type | Fuse Type | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | 4.5 | 85 °C | -40 C | 277 V | 250 V | 1.25 A | 35 A 200 A | 2-SMD Square End Block with Clip | 4.5 | cURus VDE | Slow Blow | Requires Holder Surface Mount | Board Mount (Cartridge Style Excluded) | 4.2 mm | 4 mm | 0.157 " | 0.165 in | 0.445 " | 11.3 mm |
SCHURTER Inc. | 4.5 | 85 °C | -40 C | 277 V | 250 V | 1.25 A | 35 A 200 A | 2-SMD Square End Block with Clip | 4.5 | cURus VDE | Slow Blow | Requires Holder Surface Mount | Board Mount (Cartridge Style Excluded) | 4.2 mm | 4 mm | 0.157 " | 0.165 in | 0.445 " | 11.3 mm |
