887-054 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 54POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Read Out | Card Type | Number of Positions/Bay/Row | Termination | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Color | Gender | Pitch | Pitch | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Mounting Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Dual | Non Specified - Dual Edge | 27 | Wire Wrap | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Female | 3.96 mm | 0.156 in | Gold | 0.156 " | 3.96 mm | 2 | 125 °C | -40 C | Cantilever | Through Hole | 54 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Dual | Non Specified - Dual Edge | 27 | Wire Wrap | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Female | 3.96 mm | 0.156 in | Gold | 0.128 " | 3.25 mm | 2 | 125 °C | -40 C | Cantilever | Through Hole | 54 | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Dual | Non Specified - Dual Edge | 27 | Wire Wrap | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Female | 3.96 mm | 0.156 in | Gold | 0.156 " | 3.96 mm | 2 | 125 °C | -40 C | Cantilever | Through Hole | 54 | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Dual | Non Specified - Dual Edge | 27 | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Female | 3.96 mm | 0.156 in | Gold | 0.128 " | 3.25 mm | 2 | 125 °C | -40 C | Cantilever | Through Hole | 54 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Dual | Non Specified - Dual Edge | 27 | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Female | 3.96 mm | 0.156 in | Gold | 0.128 " | 3.25 mm | 2 | 125 °C | -40 C | Cantilever | Right Angle Through Hole | 54 | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Dual | Non Specified - Dual Edge | 27 | Wire Wrap | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Female | 3.96 mm | 0.156 in | Gold | 0.116 " | 2.95 mm | 2 | 125 °C | -40 C | Cantilever | Through Hole | 54 | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Dual | Non Specified - Dual Edge | 27 | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Female | 3.96 mm | 0.156 in | Gold | 0.156 " | 3.96 mm | 2 | 125 °C | -40 C | Cantilever | Through Hole | 54 | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Dual | Non Specified - Dual Edge | 27 | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Female | 3.96 mm | 0.156 in | Gold | 0.116 " | 2.95 mm | 2 | 125 °C | -40 C | Cantilever | Through Hole | 54 | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Dual | Non Specified - Dual Edge | 27 | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Female | 3.96 mm | 0.156 in | Gold | 2 | 125 °C | -40 C | Cantilever | Through Hole | 54 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Dual | Non Specified - Dual Edge | 27 | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Female | 3.96 mm | 0.156 in | Gold | 0.128 " | 3.25 mm | 2 | 125 °C | -40 C | Cantilever | Through Hole | 54 | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded |
