SL1 Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SWITCH SNAP ACTION SPDT 5A 125V
| Part | Actuator Type | Operating Position | Operating Position | Operating Force | Switch Function | Current Rating (Amps) | Differential Travel | Differential Travel | Overtravel | Overtravel | Pretravel | Pretravel | Ingress Protection | Voltage Rating - AC | Operating Temperature [Min] [custom] | Operating Temperature [Max] [custom] | Release Force | Termination Style | Circuit | Mounting Type | Voltage Rating - DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | Overtravel Plunger | 1 in | 25.4 mm | 1200 gf | On-Mom | 5 A | 0.1 mm | 0.004 in | 3 mm | 0.118 in | 1.5 mm | 0.06 in | IP67 - Dust Tight Waterproof | 125 V | -10 °C | 158 °F | 500 gf | Screw Terminal | SPDT | ||
Honeywell Sensing and Productivity Solutions | Round (Pin Plunger) | 1 in | 25.4 mm | 1200 gf | On-Mom | 100 mA | 0.1 mm | 0.004 in | 3 mm | 0.118 in | 1.5 mm | 0.06 in | IP67 - Dust Tight Waterproof | 125 V | -10 °C | 158 °F | 500 gf | Connector | SPDT | Chassis Mount | 30 V |
