392-040 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 40POS 0.100
...
| Part | Contact Material | Contact Finish | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows | Gender | Flange Feature | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Pitch [x] | Pitch [x] | Termination | Contact Finish Thickness | Contact Finish Thickness | Card Type | Mounting Type | Material - Insulation | Read Out | Contact Type | Termination Rows | Number of Positions | Color | Number of Positions/Bay/Row [custom] | Number of Positions/Bay/Row [custom] | Number of Positions/Bay/Row [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | Gold | -40 °C | 105 ░C | 2 | Female | 4-40 Flush Mount Threaded Insert Top Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Wire Wrap | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | Through Hole | Polyester Thermoplastic | Dual | Cantilever | 2 | 40 | Black | 20 | 20 | 20 | ||||
 EDAC Inc. | Copper Alloy | Gold | -40 °C | 105 ░C | 2 | Female | Flush Mount Top Opening Unthreaded | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Wire Wrap | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | Through Hole | Polyester Thermoplastic | Dual | Cantilever | 2 | 40 | Black | 20 | 20 | 20 | 3.25 mm | 0.128 " | ||
 EDAC Inc. | Copper Alloy | Gold | -40 °C | 105 ░C | 1 | Female | Flush Mount M3 Threaded Insert Top Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Solder Wire Wrap | 10 Áin | 0.25 Ám | Non Specified - Single Edge | Through Hole Right Angle | Polyester Thermoplastic | Single | Cantilever | 1 | 40 | Black | 40 | ||||||
 EDAC Inc. | Copper Alloy | Gold | -40 °C | 105 ░C | 1 | Female | Flush Mount M3 Threaded Insert Top Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Wire Wrap | 10 Áin | 0.25 Ám | Non Specified - Single Edge | Through Hole | Polyester Thermoplastic | Single | Cantilever | 1 | 40 | Black | 40 | ||||||
 EDAC Inc. | Copper Alloy | Gold | -40 °C | 105 ░C | 1 | Female | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Solder | 10 Áin | 0.25 Ám | Non Specified - Single Edge | Through Hole | Polyester Thermoplastic | Single | Cantilever | 1 | 40 | Black | 40 | |||||||
 EDAC Inc. | Copper Alloy | Gold | -40 °C | 105 ░C | 2 | Female | Floating Bobbin Flush Mount | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Solder | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | Board Edge Straddle Mount | Polyester Thermoplastic | Dual | Cantilever | 2 | 40 | Black | 20 | 20 | 20 | 2.95 mm | 0.116 in | Card Extender | |
 EDAC Inc. | Copper Alloy | Gold | -40 °C | 105 ░C | 1 | Female | 4-40 Flush Mount Threaded Insert Top Opening | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Wire Wrap | 10 Áin | 0.25 Ám | Non Specified - Single Edge | Through Hole | Polyester Thermoplastic | Single | Cantilever | 1 | 40 | Black | 40 | ||||||
 EDAC Inc. | Copper Alloy | Gold | -40 °C | 105 ░C | 1 | Female | Flush Mount Top Opening Unthreaded | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Wire Wrap | 10 Áin | 0.25 Ám | Non Specified - Single Edge | Through Hole | Polyester Thermoplastic | Single | Cantilever | 1 | 40 | Black | 3.96 mm | 0.156 in | 40 | ||||
 EDAC Inc. | Copper Alloy | Gold | -40 °C | 105 ░C | 2 | Female | Floating Bobbin Flush Mount | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Wire Wrap | 10 Áin | 0.25 Ám | Non Specified - Dual Edge | Through Hole | Polyester Thermoplastic | Dual | Cantilever | 2 | 40 | Black | 20 | 20 | 20 | 2.95 mm | 0.116 in | ||
 EDAC Inc. | Copper Alloy | Gold | -40 °C | 105 ░C | 1 | Female | Flush Mount Top Opening Unthreaded | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.54 mm | 0.1 in | Solder | 10 Áin | 0.25 Ám | Non Specified - Single Edge | Through Hole | Polyester Thermoplastic | Single | Cantilever | 1 | 40 | Black | 3.96 mm | 0.156 in | 40 |
