20V Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
LINE FILTER 120V/250VAC 20A CHAS
| Part | Approval Agency | Filter Type | Applications | Current | Inductance | Termination Style | Frequency - Operating [Max] | Frequency - Operating [Min] | Voltage - Rated AC | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Configuration |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | CSA UR VDE | Single Phase | General Purpose | 20 A | 960 µH | Threaded Post (8-32) | 60 Hz | 50 Hz | 120 V 250 V | Chassis Mount | -10 °C | 40 °C | Two Stage |
 TE Connectivity Raychem Cable Protection | CSA UR VDE | Single Phase | General Purpose | 20 A | 540 µH | Quick Connect | 60 Hz | 50 Hz | 250 V | Chassis Mount | -10 °C | 40 °C | Single Stage |
 TE Connectivity Raychem Cable Protection | CSA UR VDE | Single Phase | General Purpose | 20 A | 1.76 mH | Threaded Post (8-32) | 60 Hz | 50 Hz | 250 V | Chassis Mount | -10 °C | 40 °C | Two Stage |
