VHS1-S5 Series
Manufacturer: CUI Inc.
Beta
⌘K
DC DC CONVERTER 12V 1W
| Part | Features | Applications | Current - Output (Max) [Max] | Voltage - Isolation | Number of Outputs | Approval Agency | Mounting Type | Voltage - Output 1 | Package / Case | Voltage - Input (Min) [Min] | Type | Operating Temperature [Max] | Operating Temperature [Min] | Standard Number | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Efficiency | Voltage - Input (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | SCP | Medical | 84 mA | 6000 VDC | 1 | UL | Through Hole | 12 V | 7-SIP Module 4 Leads | 4.5 V | Isolated Module | 85 °C | -40 C | 60950-1 | 12.5 mm | 0.49 " | 0.77 in | 0.39 in | 9.8 mm | 19.5 mm | 75 % | 5.5 V |
CUI Inc. | SCP | Medical | 200 mA | 6000 VDC | 1 | CB Scheme IEC UL | Through Hole | 5 V | 7-SIP Module 4 Leads | 4.5 V | Isolated Module | 85 °C | -40 C | 60950-1 | 12.5 mm | 0.49 " | 0.77 in | 0.39 in | 9.8 mm | 19.5 mm | 72 % | 5.5 V |
CUI Inc. | SCP | Medical | 111 mA | 6000 VDC | 1 | UL | Through Hole | 9 V | 7-SIP Module 4 Leads | 4.5 V | Isolated Module | 105 ░C | -40 C | 60950-1 | 12.5 mm | 0.49 " | 0.77 in | 0.39 in | 9.8 mm | 19.5 mm | 79 % | 5.5 V |
CUI Inc. | SCP | Medical | 67 mA | 6000 VDC | 1 | UL | Through Hole | 15 V | 7-SIP Module 4 Leads | 4.5 V | Isolated Module | 85 °C | -40 C | 60950-1 | 12.5 mm | 0.49 " | 0.77 in | 0.39 in | 9.8 mm | 19.5 mm | 75 % | 5.5 V |
