2823336 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

50P,2MM,SHRD HDR,DRVT,2.8,SN,TB

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Length - Post [x]	Contact Length - Post [x]	Mounting Type	Insulation Height [custom]	Insulation Height [custom]	Pitch - Mating [x]	Pitch - Mating [x]	Insulation Material	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Mating	Contact Length - Mating	Number of Positions Loaded	Contact Type	Shrouding	Number of Rows	Voltage Rating	Contact Finish - Post	Row Spacing - Mating	Row Spacing - Mating	Connector Type	Material Flammability Rating	Current Rating (Amps)	Termination	Fastening Type	Number of Positions	Insulation Color	Contact Material	Contact Shape	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions
TE Connectivity Raychem Cable Protection 5-2823336-0	0.3 µm	12 µin	0.11 in	2.8 mm	Through Hole	5.51 mm	0.217 in	0.079 in	2 mm	Thermoplastic	118.1 µin	3 µm	4 mm	0.157 in	All	Male Pin	Shrouded - 2 Wall	2	125 VAC	Tin	0.079 in	2 mm	Header	UL94 V-0	2 A	Solder	Detent Lock	50	Black	Phosphor Bronze	Square	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 2823336-8	0.3 µm	12 µin	0.11 in	2.8 mm	Through Hole	5.51 mm	0.217 in	0.079 in	2 mm	Thermoplastic	118.1 µin	3 µm	4 mm	0.157 in	All	Male Pin	Shrouded - 2 Wall	2	125 VAC	Tin	0.079 in	2 mm	Header	UL94 V-0	2 A	Solder	Detent Lock	8	Black	Phosphor Bronze	Square	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 1-2823336-8	0.3 µm	12 µin	0.11 in	2.8 mm	Through Hole	5.51 mm	0.217 in	0.079 in	2 mm	Thermoplastic	118.1 µin	3 µm	4 mm	0.157 in	All	Male Pin	Shrouded - 2 Wall	2	125 VAC	Tin	0.079 in	2 mm	Header	UL94 V-0	2 A	Solder	Detent Lock	18	Black	Phosphor Bronze	Square	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 1-2823336-0	0.3 µm	12 µin	0.11 in	2.8 mm	Through Hole	5.51 mm	0.217 in	0.079 in	2 mm	Thermoplastic	118.1 µin	3 µm	4 mm	0.157 in	All	Male Pin	Shrouded - 2 Wall	2	125 VAC	Tin	0.079 in	2 mm	Header	UL94 V-0	2 A	Solder	Detent Lock	10	Black	Phosphor Bronze	Square	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 2-2823336-0	0.3 µm	12 µin	0.11 in	2.8 mm	Through Hole	5.51 mm	0.217 in	0.079 in	2 mm	Thermoplastic	118.1 µin	3 µm	4 mm	0.157 in	All	Male Pin	Shrouded - 2 Wall	2	125 VAC	Tin	0.079 in	2 mm	Header	UL94 V-0	2 A	Solder	Detent Lock	20	Black	Phosphor Bronze	Square	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 2823336-4	0.3 µm	12 µin	0.11 in	2.8 mm	Through Hole	5.51 mm	0.217 in	0.079 in	2 mm	Thermoplastic	118.1 µin	3 µm	4 mm	0.157 in	All	Male Pin	Shrouded - 2 Wall	2	125 VAC	Tin	0.079 in	2 mm	Header	UL94 V-0	2 A	Solder	Detent Lock	4	Black	Phosphor Bronze	Square	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 2-2823336-4	0.3 µm	12 µin	0.11 in	2.8 mm	Through Hole	5.51 mm	0.217 in	0.079 in	2 mm	Thermoplastic	118.1 µin	3 µm	4 mm	0.157 in	All	Male Pin	Shrouded - 2 Wall	2	125 VAC	Tin	0.079 in	2 mm	Header	UL94 V-0	2 A	Solder	Detent Lock	24	Black	Phosphor Bronze	Square	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 1-2823336-4	0.3 µm	12 µin	0.11 in	2.8 mm	Through Hole	5.51 mm	0.217 in	0.079 in	2 mm	Thermoplastic	118.1 µin	3 µm	4 mm	0.157 in	All	Male Pin	Shrouded - 2 Wall	2	125 VAC	Tin	0.079 in	2 mm	Header	UL94 V-0	2 A	Solder	Detent Lock	14	Black	Phosphor Bronze	Square	-40 °C	105 ░C
TE Connectivity Raychem Cable Protection 1-2823336-6	0.3 µm	12 µin	0.11 in	2.8 mm	Through Hole	5.51 mm	0.217 in	0.079 in	2 mm	Thermoplastic	118.1 µin	3 µm	4 mm	0.157 in	All	Male Pin	Shrouded - 2 Wall	2	125 VAC	Tin	0.079 in	2 mm	Header	UL94 V-0	2 A	Solder	Detent Lock		Black	Phosphor Bronze	Square	-40 °C	105 ░C	16
