837-050 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 50POS 0.156
...
| Part | Color | Pitch [x] | Pitch [x] | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Number of Positions/Bay/Row [custom] | Read Out | Contact Finish | Termination Rows | Termination | Mounting Type | Number of Rows | Contact Type | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Contact Material | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Gender | Flange Feature | Flange Feature | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Green | 0.156 in | 3.96 mm | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Non Specified - Dual Edge | 25 | Dual | Gold | 2 | Wire Wrap | Through Hole | 2 | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | 50 | 10 Áin | 0.25 Ám | Female | Side Mount Opening Unthreaded | 3.25 mm | 0.128 in | |||
 EDAC Inc. | Green | 0.156 in | 3.96 mm | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Non Specified - Dual Edge | 25 | Dual | Gold | 2 | Solder Eyelet(s) | Through Hole | 2 | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | 50 | 10 Áin | 0.25 Ám | Female | Floating Bobbin Flush Mount | 0.116 in | 2.95 mm | |||
 EDAC Inc. | Green | 0.156 in | 3.96 mm | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Non Specified - Dual Edge | 25 | Dual | Gold | 2 | Solder | Board Edge Straddle Mount | 2 | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | 50 | 10 Áin | 0.25 Ám | Female | Floating Bobbin Top Mount Opening | 0.116 in | 2.95 mm | Card Extender | ||
 EDAC Inc. | Green | 0.156 in | 3.96 mm | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Non Specified - Dual Edge | 25 | Dual | Gold | 2 | Solder | Through Hole | 2 | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | 50 | 10 Áin | 0.25 Ám | Female | Top Mount Opening Unthreaded | 0.156 in | 3.96 mm | |||
 EDAC Inc. | Green | 0.156 in | 3.96 mm | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Non Specified - Dual Edge | 25 | Dual | Gold | 2 | Solder | Board Edge Straddle Mount | 2 | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | 50 | 10 Áin | 0.25 Ám | Female | Top Mount Opening Unthreaded | 0.156 in | 3.96 mm | Card Extender | ||
 EDAC Inc. | Green | 0.156 in | 3.96 mm | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Non Specified - Dual Edge | 25 | Dual | Gold | 2 | Solder | Through Hole Right Angle | 2 | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | 50 | 10 Áin | 0.25 Ám | Female | M3 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Green | 0.156 in | 3.96 mm | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Non Specified - Dual Edge | 25 | Dual | Gold | 2 | Solder | Board Edge Straddle Mount | 2 | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | 50 | 10 Áin | 0.25 Ám | Female | Card Extender | |||||
 EDAC Inc. | Green | 0.156 in | 3.96 mm | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Non Specified - Dual Edge | 25 | Dual | Gold | 2 | Wire Wrap | Through Hole | 2 | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | 50 | 10 Áin | 0.25 Ám | Female | Top Mount Opening Unthreaded | 0.156 in | 3.96 mm | |||
 EDAC Inc. | Green | 0.156 in | 3.96 mm | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Non Specified - Dual Edge | 25 | Dual | Gold | 2 | Solder | Through Hole Right Angle | 2 | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | 50 | 10 Áin | 0.25 Ám | Female | 4-40 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Green | 0.156 in | 3.96 mm | Diallyl Phthalate (DAP) | 125 °C | -40 °C | Non Specified - Dual Edge | 25 | Dual | Gold | 2 | Wire Wrap | Through Hole | 2 | Cantilever | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | 50 | 10 Áin | 0.25 Ám | Female | 3.25 mm | 0.128 in |
