857-066 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 66POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Mounting Type | Termination | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Color | Card Type | Number of Rows [custom] | Read Out | Pitch | Pitch | Contact Material | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Type | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 66 | Tin | 125 °C | -40 C | Female | Black | Non Specified - Dual Edge | 2 | Dual | 3.96 mm | 0.156 in | Copper Alloy | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Semi Bellows | 33 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 66 | Tin | 125 °C | -40 C | Female | Black | Non Specified - Dual Edge | 2 | Single | 3.96 mm | 0.156 in | Copper Alloy | Semi Bellows | 33 | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 66 | Tin | 125 °C | -40 C | Female | Black | Non Specified - Dual Edge | 2 | Dual | 3.96 mm | 0.156 in | Copper Alloy | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Semi Bellows | 33 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 66 | Tin | 125 °C | -40 C | Female | Black | Non Specified - Dual Edge | 2 | Dual | 3.96 mm | 0.156 in | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | 33 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 66 | Gold | 125 °C | -40 C | Female | Black | Non Specified - Dual Edge | 2 | Dual | 3.96 mm | 0.156 in | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | Semi Bellows | 33 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 66 | Tin | 125 °C | -40 C | Female | Black | Non Specified - Dual Edge | 2 | Dual | 3.96 mm | 0.156 in | Copper Alloy | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Semi Bellows | 33 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Board Edge Straddle Mount | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 66 | Gold | 125 °C | -40 C | Female | Black | Non Specified - Dual Edge | 2 | Dual | 3.96 mm | 0.156 in | Copper Alloy | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Semi Bellows | 33 | 0.25 Ám | 10 Áin | Card Extender |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 66 | Tin | 125 °C | -40 C | Female | Black | Non Specified - Dual Edge | 2 | Dual | 3.96 mm | 0.156 in | Copper Alloy | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Semi Bellows | 33 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 66 | Tin | 125 °C | -40 C | Female | Black | Non Specified - Dual Edge | 2 | Dual | 3.96 mm | 0.156 in | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | Semi Bellows | 33 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 66 | Gold | 125 °C | -40 C | Female | Black | Non Specified - Dual Edge | 2 | Dual | 3.96 mm | 0.156 in | Copper Alloy | Semi Bellows | 33 | 0.25 Ám | 10 Áin |
