R404N0 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
TERMINATION: SMA M 18 GHZ 2W WIT
| Part | Body Material | Dielectric Material | Connector Style | Connector Type | Features | Impedance | Mounting Type | Contact Material | Frequency - Max [Max] | Contact Finish | Body Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Stainless Steel | Polytetrafluoroethylene (PTFE) | SMA | Plug Male Pin | Chain | 50 Ohms | Cap Free Hanging | Brass | 18 GHz | Gold | |
 Radiall USA, Inc. | Stainless Steel | Polytetrafluoroethylene (PTFE) | SMA | Female Socket Jack | 50 Ohms | Cap Free Hanging | Beryllium Copper | 26.5 GHz | Gold | Gold | |
 Radiall USA, Inc. | Stainless Steel | Polytetrafluoroethylene (PTFE) | SMA | Plug Male Pin | Cord | 50 Ohms | Cap Free Hanging | Brass | 18 GHz | Gold | |
Radiall USA, Inc. | Stainless Steel | Polytetrafluoroethylene (PTFE) | SMA | Female Socket Jack | 50 Ohms | Cap Free Hanging | Beryllium Copper | 26.5 GHz | Gold | Gold | |
 Radiall USA, Inc. | Stainless Steel | Polytetrafluoroethylene (PTFE) | SMA | Plug Male Pin | 50 Ohms | Cap Free Hanging | Brass | 26.5 GHz | Gold | Gold | |
Radiall USA, Inc. | Stainless Steel | Polytetrafluoroethylene (PTFE) | SMA | Female Socket Jack | 50 Ohms | Cap Free Hanging | Beryllium Copper | 18 GHz | Gold | Gold | |
Radiall USA, Inc. | Stainless Steel | Polytetrafluoroethylene (PTFE) | SMA | Plug Male Pin | Cord | 50 Ohms | Cap Free Hanging | Brass | 18 GHz | Gold | |
Radiall USA, Inc. | Stainless Steel | Polytetrafluoroethylene (PTFE) | SMA | Plug Male Pin | Chain | 50 Ohms | Cap Free Hanging | Brass | 18 GHz | Gold | |
Radiall USA, Inc. | Stainless Steel | Polytetrafluoroethylene (PTFE) | SMA | Plug Male Pin | 50 Ohms | Cap Free Hanging | Brass | 18 GHz | Gold | ||
Radiall USA, Inc. | Stainless Steel | Polytetrafluoroethylene (PTFE) | SMA | Plug Male Pin | 50 Ohms | Cap Free Hanging | Brass | 26.5 GHz | Gold |
