002212 Series

Headers & Wire Housings KK 100 HDR FRLK RTAN 10 CKT GOLD

Manufacturer: Molex

Catalog

Headers & Wire Housings KK 100 HDR FRLK RTAN 10 CKT GOLD

Catalog

Headers & Wire Housings KK 100 HDR FRLK RTAN 10 CKT GOLD

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Applications	Material Flammability Rating	Style	Mounting Type	Number of Positions Loaded	Shrouding	Termination	Connector Type	Contact Length - Mating	Contact Length - Mating	Contact Material	Pitch - Mating	Pitch - Mating	Number of Positions	Fastening Type	Contact Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Material	Contact Finish - Mating	Contact Finish - Post	Number of Rows	Contact Length - Post [x]	Contact Length - Post [x]	Contact Shape	Insulation Color	Insulation Height [z]	Insulation Height [z]	Contact Length - Post	Contact Length - Post	Insulation Height	Insulation Height
Molex 0022124022	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	Board to Board Cable	Right Angle Through Hole	All	Shrouded - 1 Wall	Solder	Header	6.7 mm	0.264 in	Brass	0.1 "	2.54 mm	2	Friction Lock	Male Pin	0.51 µm	20 µin	Nylon 6/6 Polyamide (PA66)	Gold	Tin	1	3.81 mm	0.15 in	Square	Natural	0.228 "	5.8 mm
Molex 0022124032	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	Board to Board Cable	Right Angle Through Hole	All	Shrouded - 1 Wall	Solder	Header	6.7 mm	0.264 in	Brass	0.1 "	2.54 mm		Friction Lock	Male Pin	0.51 µm	20 µin	Nylon 6/6 Polyamide (PA66)	Gold	Tin	1	3.81 mm	0.15 in	Square	Natural	0.228 "	5.8 mm
Molex 0022124092	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	Board to Board Cable	Right Angle Through Hole	All	Shrouded - 1 Wall	Solder	Header	6.7 mm	0.264 in	Brass	0.1 "	2.54 mm	9	Friction Lock	Male Pin	0.51 µm	20 µin	Nylon 6/6 Polyamide (PA66)	Gold	Tin	1	3.81 mm	0.15 in	Square	Natural	0.228 "	5.8 mm
Molex 0022122071	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	Board to Board Cable	Right Angle Through Hole	All	Unshrouded	Solder	Header	9.37 mm	0.369 in		0.1 "	2.54 mm	7	Push-Pull	Male Pin	0.51 µm	20 µin	Nylon Polyamide (PA)	Gold	Tin	1			Square	White	0.13 in	3.3 mm	0.124 in	3.15 mm
Molex 0022122031	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	Board to Board Cable	Right Angle Through Hole	All	Unshrouded	Solder	Header	9.37 mm	0.369 in		0.1 "	2.54 mm		Push-Pull	Male Pin	0.51 µm	20 µin	Nylon Polyamide (PA)	Gold	Tin	1			Square	White	0.13 in	3.3 mm	0.124 in	3.15 mm
Molex 0022122174	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	Board to Board Cable	Right Angle Through Hole	All	Shrouded - 1 Wall	Solder	Header	6.7 mm	0.264 in	Brass	0.1 "	2.54 mm		Friction Lock	Male Pin	0.51 µm	20 µin	Nylon Polyamide (PA)	Gold	Tin	1			Square	White			0.141 in	3.58 mm	6.35 mm	0.25 in
Molex 0022122186	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	Board to Board Cable	Right Angle Through Hole	All	Shrouded - 1 Wall	Solder	Header	6.7 mm	0.264 in	Brass	0.1 "	2.54 mm	18	Friction Lock	Male Pin	0.76 Ám	30 Áin	Nylon Polyamide (PA)	Gold	Tin	1			Square	White			0.141 in	3.58 mm	6.35 mm	0.25 in
Molex 0022121082				UL94 V-0	Board to Cable/Wire	Right Angle Through Hole	All	Shrouded - 1 Wall	Solder	Header	7.49 mm	0.295 in		0.098 in	2.5 mm	8	Friction Lock	Male Pin	0.35 µm	13.8 µin	Nylon 6/6 Polyamide (PA66)	Gold		1		0.134 "	Square	Natural				3.4 mm
Molex 0022122091	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	Board to Board Cable	Right Angle Through Hole	All	Unshrouded	Solder	Header	9.37 mm	0.369 in		0.1 "	2.54 mm	9	Push-Pull	Male Pin	0.51 µm	20 µin	Nylon Polyamide (PA)	Gold	Tin	1			Square	White	0.13 in	3.3 mm	0.124 in	3.15 mm
Molex 0022122284	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	Board to Board Cable	Right Angle Through Hole	All	Shrouded - 1 Wall	Solder	Header	6.7 mm	0.264 in	Brass	0.1 "	2.54 mm	28	Friction Lock	Male Pin	0.51 µm	20 µin	Nylon Polyamide (PA)	Gold	Tin	1			Square	White			0.141 in	3.58 mm	6.35 mm	0.25 in
