9GA0405 Series

Catalog

FAN AXIAL 40X20MM BALL 5VDC WIRE

Part	Current Rating (Amps)	Voltage Range [Max]	Voltage Range [Min]	Material - Blade	Material - Frame	Lifetime @ Temp.	Width [y]	Static Pressure	Static Pressure	Weight	Weight	Air Flow	Air Flow	Noise	RPM	Voltage - Rated	Size / Dimension [x]	Size / Dimension [z]	Fan Type	Approval Agency	Power (Watts)	Operating Temperature [Min]	Operating Temperature [Max]	Bearing Type	Termination	Features	Static Pressure	Weight [custom]	Weight [custom]
Sanyo Denki America Inc. 9GA0405H6002	0.35 A	5.5 V	4.5 V	Plastic	Plastic	40000 Hrs	20 mm	191.8 Pa	0.77 in H2O	0.078 lb	35.38 g	11.7 CFM	0.328 mł/min	40 dB(A)	12400 RPM	5 V	40 mm	40 mm	Tubeaxial	CSA TUV UL	1.75 W	-20 ░C	70 °C	Ball	2 Wire Leads
Sanyo Denki America Inc. 9GA0405H6001	0.35 A	5.5 V	4.5 V	Plastic	Plastic	40000 Hrs	20 mm	191.8 Pa	0.77 in H2O	0.078 lb	35.38 g	11.7 CFM	0.328 mł/min	40 dB(A)	12400 RPM	5 V	40 mm	40 mm	Tubeaxial	CSA TUV UL	1.75 W	-20 ░C	70 °C	Ball	3 Wire Leads	Locked Rotor Protection Speed Sensor (Tach)
Sanyo Denki America Inc. 9GA0405F6001	0.18 A	5.5 V	4.5 V	Plastic	Plastic		20 mm		79.7 Pa	0.078 lb	35.38 g	7.4 CFM	0.207 m³/min	28 dB	8000 RPM	5 V	40 mm	40 mm	Tubeaxial	CSA TUV UL	0.9 W	-20 ░C	70 °C	Ball	3 Wire Leads	Locked Rotor Protection Speed Sensor (Tach)	0.32 in H2O
Sanyo Denki America Inc. 9GA0405P6H001	0.35 A	5.5 V	4.5 V	Plastic	Plastic	40000 Hrs	20 mm	191.8 Pa	0.77 in H2O			11.7 CFM	0.328 mł/min	40 dB(A)	12400 RPM	5 V	40 mm	40 mm	Tubeaxial	CSA TUV UL	1.75 W	-20 ░C	70 °C	Ball	4 Wire Leads	Locked Rotor Protection PWM Control Speed Sensor (Tach)		0.077 lb	34.93 g
