9GA0412 Series
DC Fans DC Axial Fan, 80x80x32mm, 24VDC, Low Power
Manufacturer: Sanyo Denki America Inc.
Catalog
DC Fans DC Axial Fan, 80x80x32mm, 24VDC, Low Power
DC Fans DC Axial Fan, 80x80x32mm, 24VDC, Low Power
DC Fans DC Axial Fan, 80x80x32mm, 24VDC, Low Power
DC Fans DC Axial Fan, 80x80x32mm, 24VDC, Low Power
| Part | Voltage Range [Max] | Voltage Range [Min] | Material - Blade | Current Rating (Amps) | Material - Frame | Lifetime @ Temp. | Approval Agency | Termination | Features | Size / Dimension [x] | Size / Dimension [z] | Fan Type | Operating Temperature [Min] | Operating Temperature [Max] | RPM | Weight | Weight | Width [y] | Noise | Static Pressure | Static Pressure | Voltage - Rated | Bearing Type | Lifetime @ Temp. | Width [x] | Static Pressure | Air Flow | Air Flow | Power (Watts) | Weight [custom] | Weight [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Sanyo Denki America Inc. | 13.8 VDC | 7 V | Plastic | 0.17 A | Plastic | Varies Based on Temperature | CSA TUV UL | 3 Wire Leads | Locked Rotor Sensor | 40 mm | 40 mm | Tubeaxial | -20 ░C | 70 °C | 13100 RPM | 0.062 lb | 28.12 g | 15 mm | 42 dB | 191.8 Pa | 0.77 in H2O | 12 VDC | Ball | ||||||||
Sanyo Denki America Inc. | 13.2 VDC | 10.8 VDC | Plastic | 490 mA | Plastic | CSA TUV UL | 3 Wire Leads | Locked Rotor Protection Speed Sensor (Tach) | 40 mm | 40 mm | Tubeaxial | -20 ░C | 70 °C | 18000 RPM | 0.117 lb | 53.07 g | 54 dB | 535 Pa | 12 VDC | Ball | 40000 Hrs | 28 mm | 2.15 in H2O | 23.7 CFM | 0.664 m³/min | 5.88 W | |||||
Sanyo Denki America Inc. | 13.2 VDC | 10.8 VDC | Plastic | 0.21 A | Plastic | CSA TUV UL | 4 Wire Leads | Locked Rotor Protection PWM Control Speed Sensor (Tach) | 40 mm | 40 mm | Tubeaxial | -20 ░C | 70 °C | 12500 RPM | 0.117 lb | 53.07 g | 47 dB | 258 Pa | 12 VDC | Ball | 40000 Hrs | 28 mm | 1.04 in H2O | 16.2 CFM | 0.454 m³/min | 2.52 W | |||||
Sanyo Denki America Inc. | 13.2 VDC | 10.8 VDC | Plastic | 390 mA | Plastic | CSA TUV UL | 3 Wire Leads | Locked Rotor Protection Speed Sensor (Tach) | 40 mm | 40 mm | Tubeaxial | -20 ░C | 70 °C | 16500 RPM | 0.117 lb | 53.07 g | 53 dB | 450.8 Pa | 12 VDC | Ball | 40000 Hrs | 28 mm | 1.81 in H2O | 21.5 CFM | 0.602 m³/min | ||||||
Sanyo Denki America Inc. | 13.2 VDC | 10.8 VDC | Plastic | 0.28 A | Plastic | CSA TUV UL | 2 Wire Leads | 40 mm | 40 mm | Tubeaxial | -20 ░C | 70 °C | 14500 RPM | 0.117 lb | 53.07 g | 50 dB(A) | 346.2 Pa | 12 VDC | Ball | 40000 Hrs | 28 mm | 1.39 in H2O | 19.1 CFM | 0.535 mł/min | 3.36 W | ||||||
Sanyo Denki America Inc. | 13.2 VDC | 10.8 VDC | Plastic | 390 mA | Plastic | CSA TUV UL | 4 Wire Leads | Locked Rotor Protection PWM Control Speed Sensor (Tach) | 40 mm | 40 mm | Tubeaxial | -20 ░C | 70 °C | 16500 RPM | 0.117 lb | 53.07 g | 53 dB | 450.8 Pa | 12 VDC | Ball | 40000 Hrs | 28 mm | 1.81 in H2O | 21.5 CFM | 0.602 m³/min | ||||||
Sanyo Denki America Inc. | 13.2 VDC | 10.8 VDC | Plastic | 0.28 A | Plastic | CSA TUV UL | 3 Wire Leads | Locked Rotor Sensor | 40 mm | 40 mm | Tubeaxial | -20 ░C | 70 °C | 14500 RPM | 0.117 lb | 53.07 g | 50 dB(A) | 346.2 Pa | 12 VDC | Ball | 40000 Hrs | 28 mm | 1.39 in H2O | 19.1 CFM | 0.535 mł/min | 3.36 W | |||||
Sanyo Denki America Inc. | 13.8 VDC | 10.2 VDC | Plastic | Plastic | CSA TUV UL | 4 Wire Leads | Locked Rotor Protection PWM Control Speed Sensor (Tach) | 40 mm | 40 mm | Tubeaxial | -20 ░C | 70 °C | 8000 RPM | 20 mm | 28 dB | 79.5 Pa | 12 VDC | Ball | 0.319 in H2O | 7.4 CFM | 0.207 m³/min | 960 mW | 0.077 lb | 34.93 g | |||||||
Sanyo Denki America Inc. | 13.2 VDC | 10.8 VDC | Plastic | 920 mA | Plastic | CSA TUV UL | 4 Wire Leads | Locked Rotor Protection PWM Control Speed Sensor (Tach) | 40 mm | 40 mm | Tubeaxial | -20 ░C | 70 °C | 22000 RPM | 0.117 lb | 53.07 g | 61 dB(A) | 800 Pa | 12 VDC | Ball | 40000 Hrs | 28 mm | 3.21 in H2O | 28.6 CFM | 0.801 m³/min | 11.04 W | |||||
Sanyo Denki America Inc. | 13.8 VDC | 10.2 VDC | Plastic | 0.23 A | Plastic | 4 Position Rectangular Connector | Locked Rotor Protection PWM Control Speed Sensor (Tach) | 40 mm | 40 mm | Tubeaxial | -20 ░C | 70 °C | 16000 RPM | 0.078 lb | 35.38 g | 20 mm | 47 dB | 12 VDC | Ball |
