837-048 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 48POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Features | Termination | Gender | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Read Out | Contact Finish | Pitch | Pitch | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Color | Number of Positions/Bay/Row | Card Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Card Extender | Solder | Female | 48 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | 0.25 Ám | 10 Áin | Dual | Gold | 3.96 mm | 0.156 in | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | 125 °C | -40 C | Green | 24 | Non Specified - Dual Edge |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder | Female | 48 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Copper Alloy | 0.25 Ám | 10 Áin | Dual | Gold | 3.96 mm | 0.156 in | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | 125 °C | -40 C | Green | 24 | Non Specified - Dual Edge | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Wire Wrap | Female | 48 | Copper Alloy | 0.25 Ám | 10 Áin | Dual | Gold | 3.96 mm | 0.156 in | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | 125 °C | -40 C | Green | 24 | Non Specified - Dual Edge | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder | Female | 48 | 3.25 mm | 0.128 " | Copper Alloy | 0.25 Ám | 10 Áin | Dual | Gold | 3.96 mm | 0.156 in | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | 125 °C | -40 C | Green | 24 | Non Specified - Dual Edge | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Card Extender | Solder | Female | 48 | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | 0.25 Ám | 10 Áin | Dual | Gold | 3.96 mm | 0.156 in | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | 125 °C | -40 C | Green | 24 | Non Specified - Dual Edge | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Card Extender | Solder | Female | 48 | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | 0.25 Ám | 10 Áin | Dual | Gold | 3.96 mm | 0.156 in | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | 125 °C | -40 C | Green | 24 | Non Specified - Dual Edge | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Card Extender | Solder | Female | 48 | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | 0.25 Ám | 10 Áin | Dual | Gold | 3.96 mm | 0.156 in | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | 125 °C | -40 C | Green | 24 | Non Specified - Dual Edge |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder | Female | 48 | Copper Alloy | 0.25 Ám | 10 Áin | Dual | Gold | 3.96 mm | 0.156 in | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | 125 °C | -40 C | Green | 24 | Non Specified - Dual Edge | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder | Female | 48 | 3.25 mm | 0.128 " | Copper Alloy | 0.25 Ám | 10 Áin | Dual | Gold | 3.96 mm | 0.156 in | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | 125 °C | -40 C | Green | 24 | Non Specified - Dual Edge | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Solder | Female | 48 | Copper Alloy | 0.25 Ám | 10 Áin | Dual | Gold | 3.96 mm | 0.156 in | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | 125 °C | -40 C | Green | 24 | Non Specified - Dual Edge |
