396-042 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 42POS 0.125
| Part | Material - Insulation | Termination Rows | Termination | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Number of Positions/Bay/Row | Contact Material | Mounting Type | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Read Out | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Color | Card Type | Number of Rows | Contact Finish | Pitch | Pitch | Flange Feature | Features | Termination Rows [custom] | Number of Positions/Bay/Row [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | 0.25 Ám | 10 Áin | Cantilever | 42 | Copper Alloy | Through Hole | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 42 | Single | -40 C | 105 ░C | Female | Black | Non Specified - Single Edge | 1 | Gold | 3.18 mm | 0.125 in | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder Wire Wrap | 0.25 Ám | 10 Áin | Cantilever | 42 | Copper Alloy | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 42 | Single | -40 C | 105 ░C | Female | Black | Non Specified - Single Edge | 1 | Gold | 3.18 mm | 0.125 in | 4-40 Threaded Insert Top Mount Opening | Card Guides | |||||
 EDAC Inc. | Polyester Thermoplastic | Solder Wire Wrap | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 42 | Dual | -40 C | 105 ░C | Female | Black | Non Specified - Dual Edge | Gold | 3.18 mm | 0.125 in | M3 Threaded Insert Top Mount Opening | 2 | 21 | 2 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Wire Wrap | 0.25 Ám | 10 Áin | Cantilever | 42 | Copper Alloy | Through Hole | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 42 | Single | -40 C | 105 ░C | Female | Black | Non Specified - Single Edge | 1 | Gold | 3.18 mm | 0.125 in | Flush Mount Top Opening Unthreaded | ||||
 EDAC Inc. | Polyester Thermoplastic | Solder | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | Through Hole | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 42 | Dual | -40 C | 105 ░C | Female | Black | Non Specified - Dual Edge | Gold | 3.18 mm | 0.125 in | Flush Mount Side Opening Unthreaded | 2 | 21 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | Solder | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 42 | Dual | -40 C | 105 ░C | Female | Black | Non Specified - Dual Edge | Gold | 3.18 mm | 0.125 in | 4-40 Flush Mount Threaded Insert Top Opening | 2 | 21 | 2 | ||||||
 EDAC Inc. | Polyester Thermoplastic | Solder Wire Wrap | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 42 | Dual | -40 C | 105 ░C | Female | Black | Non Specified - Dual Edge | Gold | 3.18 mm | 0.125 in | 4-40 Threaded Insert Top Mount Opening | 2 | 21 | 2 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | 0.25 Ám | 10 Áin | Cantilever | 42 | Copper Alloy | Through Hole | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 42 | Single | -40 C | 105 ░C | Female | Black | Non Specified - Single Edge | 1 | Gold | 3.18 mm | 0.125 in | Floating Bobbin Top Mount Opening | ||||
 EDAC Inc. | Polyester Thermoplastic | Solder | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | Through Hole | 3.96 mm | 0.156 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 42 | Dual | -40 C | 105 ░C | Female | Black | Non Specified - Dual Edge | Gold | 3.18 mm | 0.125 in | Flush Mount Top Opening Unthreaded | 2 | 21 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | Solder | 0.25 Ám | 10 Áin | Cantilever | Copper Alloy | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 42 | Dual | -40 C | 105 ░C | Female | Black | Non Specified - Dual Edge | Gold | 3.18 mm | 0.125 in | Flush Mount M3 Threaded Insert Top Opening | 2 | 21 | 2 |
