PUP6AV Series

Catalog

CABLE CAT6A 8CON 23AWG GRAY 250'

Part	Length	Length [x]	Length	Conductor Strand	Number of Conductors	Wire Gauge	Ratings	Cable Type	Conductor Material	Jacket (Insulation) Material	Length [x]	Conductor Insulation	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Operating Temperature [Min]	Operating Temperature [Max]	Shield Type	Jacket Color	Features
Panduit Corp PUP6AV04IG-G	15.24 m 76.2 m 304.8 m	50 ft 100 ft	1000 ft 3000 "	Solid	8	23 AWG	UL Style CMP	Multi-Pair Cat6a	Copper	Plenum Poly-Vinyl Chloride (PVC)	30.5 m	Fluorinated Ethylene-Propylene (FEP) Polyethylene (PE)	0.25 "	6.35 mm	-20 C	90 °C	Foil	Gray	Flame Retardant
Panduit Corp PUP6AV04GR-G	15.24 m 76.2 m 304.8 m	50 ft 100 ft 500 '	1000 ft 3000 "	Solid	8	23 AWG	UL Style CMP	Multi-Pair Cat6a	Copper	Plenum Poly-Vinyl Chloride (PVC)	30.5 m 152.4 m	Fluorinated Ethylene-Propylene (FEP) Polyethylene (PE)	0.25 "	6.35 mm	-20 C	90 °C	Foil	Green	Flame Retardant
Panduit Corp PUP6AV04VL-G	15.24 m 76.2 m 304.8 m	50 ft 500 '	1000 ft 3000 "	Solid	8	23 AWG	UL Style CMP	Multi-Pair Cat6a	Copper	Plenum Poly-Vinyl Chloride (PVC)	152.4 m	Fluorinated Ethylene-Propylene (FEP) Polyethylene (PE)	0.25 "	6.35 mm	-20 C	90 °C	Foil	Violet	Flame Retardant
Panduit Corp PUP6AV04BL-G	15.24 m 76.2 m 304.8 m	50 ft 100 ft	1000 ft 3000 "	Solid	8	23 AWG	UL Style CMP	Multi-Pair Cat6a	Copper	Plenum Poly-Vinyl Chloride (PVC)	30.5 m	Fluorinated Ethylene-Propylene (FEP) Polyethylene (PE)	0.25 "	6.35 mm	-20 C	90 °C	Foil	Black	Flame Retardant
Panduit Corp PUP6AV04RD-G	15.24 m 76.2 m 304.8 m	50 ft	1000 ft 3000 "	Solid	8	23 AWG	UL Style CMP	Multi-Pair Cat6a	Copper	Plenum Poly-Vinyl Chloride (PVC)		Fluorinated Ethylene-Propylene (FEP) Polyethylene (PE)	0.25 "	6.35 mm	-20 C	90 °C	Foil	Red	Flame Retardant
