LYA67K Series

Catalog

LED YELLOW CLEAR SMD R/A

Part	Color	Viewing Angle	Wavelength - Peak	Current - Test	Size / Dimension [y]	Size / Dimension [x]	Height (Max) [Max] [z]	Supplier Device Package	Wavelength - Dominant	Lens Size [diameter]	Lens Transparency	Millicandela Rating	Configuration	Voltage - Forward (Vf) (Typ)	Lens Color	Lens Style	Package / Case	Mounting Type
ams-OSRAM USA INC. LY A67K-J2M1-26-0-2-R33-Z	Yellow	120 °	591 nm	2 mA	3.6 mm	4 mm	4.2 mm	SMD	587 nm	2.4 mm Dia	Clear	14 mcd	Standard	1.8 V	Colorless	Round with Flat Top	2-SMD Boomerang	Right Angle Surface Mount
ams-OSRAM USA INC. LY A67K-K2M1-26-0-2-R33-Z	Yellow	120 °	591 nm	2 mA	3.6 mm	4 mm	4.2 mm	SMD	587 nm	2.4 mm Dia	Clear	15.7 mcd	Standard	1.8 V	Colorless	Round with Flat Top	2-SMD Boomerang	Right Angle Surface Mount
ams-OSRAM USA INC. LY A67K-J2L1-26-0-2-R33-Z	Yellow	120 °	591 nm	2 mA	3.6 mm	4 mm	4.2 mm	SMD	587 nm	2.4 mm Dia	Clear	9.8 mcd	Standard	1.8 V	Colorless	Round with Flat Top	2-SMD Boomerang	Right Angle Surface Mount
