MP6601 Series

Catalog

STEPPER MOTOR DRIVER

Part	Operating Temperature [Min]	Operating Temperature [Max]	Function	Mounting Type	Current - Output	Motor Type - Stepper	Voltage - Supply [Min]	Voltage - Supply [Max]	Output Configuration	Interface	Applications	Supplier Device Package	Package / Case	Voltage - Load	Technology	Motor Type - AC, DC	Step Resolution
Monolithic Power Systems Inc. MP6601GU-Z	-40 C	125 °C	Driver - Fully Integrated Control and Power Stage	Surface Mount	2.5 A	Bipolar	4.5 V	35 V	Half Bridge (4)	Logic	Printer	24-QFN (5x5)	24-VFQFN Exposed Pad	3.3 V 5 VDC	Power MOSFET	Brushed DC	1 1/2 1/4 1/8
Monolithic Power Systems Inc. MP6601GF-Z	-40 C	125 °C	Driver - Fully Integrated Control and Power Stage	Surface Mount	2.5 A	Bipolar	4.5 V	35 V	Half Bridge (4)	Logic	Printer	28-TSSOP-EP	28-TSSOP (0.173" 4.40mm Width) Exposed Pad	3.3 V 5 VDC	Power MOSFET	Brushed DC	1 1/2 1/4 1/8
Monolithic Power Systems Inc. MP6601GF	-40 C	125 °C	Driver - Fully Integrated Control and Power Stage	Surface Mount	2.5 A	Bipolar	4.5 V	35 V	Half Bridge (4)	Logic	Printer	28-TSSOP-EP	28-TSSOP (0.173" 4.40mm Width) Exposed Pad	3.3 V 5 VDC	Power MOSFET	Brushed DC	1 1/2 1/4 1/8
Monolithic Power Systems Inc. MP6601GU-P	-40 C	125 °C	Driver - Fully Integrated Control and Power Stage	Surface Mount	2.5 A	Bipolar	4.5 V	35 V	Half Bridge (4)	Logic	Printer	24-QFN (5x5)	24-VFQFN Exposed Pad	3.3 V 5 VDC	Power MOSFET	Brushed DC	1 1/2 1/4 1/8
