PH-MVF-33 Series
Manufacturer: Adam Tech
Beta
⌘K
CONTACT SPRING LOADED SMD GOLD
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Minimum Working Height | Minimum Working Height | Operating Force - Initial | Mounting Type | Recommended Working Height | Recommended Working Height | Contact Type | Plunger Size [diameter] | Plunger Size [diameter] | Contact Finish | Mating Cycles | Maximum Working Height [Max] | Maximum Working Height [Max] | Pad Layout Dimension [diameter] | Pad Layout Dimension [diameter] | Contact Material | Minimum Working Height [Min] | Minimum Working Height [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | -55 C | 125 °C | 3.1 mm | 0.122 in | 70 gf | Surface Mount | 3.5 mm | 0.138 in | Sleeve & Plunger (Pogo Pins) | 1 mm | 0.039 in | Gold | 1000000 | 0.177 in | 4.5 mm | 0.071 in | 1.8 mm | Brass | ||
 Adam Tech | -55 C | 125 °C | 70 gf | Surface Mount | 4 mm | 0.157 in | Sleeve & Plunger (Pogo Pins) | 1 mm | 0.039 in | Gold | 1000000 | 0.197 in | 5 mm | 0.071 in | 1.8 mm | Brass | 0.142 in | 3.6 mm |
