1757838 Series
Manufacturer: TE Connectivity Aerospace, Defense and Marine
Beta
⌘K
CONN D-SUB RCPT 9POS R/A SLDR
| Part | Backset Spacing | Backset Spacing | Connector Type | Contact Finish Thickness | Contact Finish Thickness | Color | Mounting Type | Current Rating (Amps) | Operating Temperature [Min] | Operating Temperature [Max] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Shell Material, Finish | Termination | Contact Finish | Number of Rows | Contact Type | Contact Material | Flange Feature | Connector Style | Number of Positions | Shell Size, Connector Layout | Shell Size, Connector Layout |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Aerospace, Defense and Marine | 8.08 mm | 0.318 " | Receptacle Female Sockets | 10 Áin | 0.25 Ám | Black | Through Hole Right Angle | 5 A | -55 °C | 125 °C | DE E | 1 | Steel Yellow Chromate Plated Zinc | Solder | Gold | 2 | Signal | Brass | Housing/Shell (Unthreaded) | D-Sub | 9 | ||
TE Connectivity Aerospace, Defense and Marine | 8.08 mm | 0.318 " | Receptacle Female Sockets | 10 Áin | 0.25 Ám | Black | Through Hole Right Angle | 5 A | -55 °C | 125 °C | Steel Yellow Chromate Plated Zinc | Solder | Gold | 2 | Signal | Brass | Housing/Shell (Unthreaded) | D-Sub | 37 | 4 (DC C) | |||
 TE Connectivity Aerospace, Defense and Marine | 8.08 mm | 0.318 " | Receptacle Female Sockets | 10 Áin | 0.25 Ám | Black | Through Hole Right Angle | 5 A | -55 °C | 125 °C | Steel Yellow Chromate Plated Zinc | Solder | Gold | 3 | Signal | Brass | Housing/Shell (Unthreaded) | D-Sub | 50 | 5 | |||
TE Connectivity Aerospace, Defense and Marine | 8.08 mm | 0.318 " | Receptacle Female Sockets | 10 Áin | 0.25 Ám | Black | Through Hole Right Angle | 5 A | -55 °C | 125 °C | B DB | 3 | Steel Yellow Chromate Plated Zinc | Solder | Gold | 2 | Signal | Brass | Housing/Shell (Unthreaded) | D-Sub |
