EN3C5M Series

Catalog

CIRCULAR CONNECTOR, EN3 SERIES, CABLE MOUNT PLUG, 5 CONTACTS, SOLDER PIN, BAYONET

Part	Number of Positions	Voltage Rating	Insert Material	Fastening Type	Color	Current Rating (Amps)	Applications	Orientation	Contact Material	Cable Opening [Min]	Cable Opening [Max]	Cable Opening [Min]	Cable Opening [Max]	Ingress Protection	Backshell Material, Plating	Operating Temperature [Min]	Operating Temperature [Max]	Shielding	Material Flammability Rating	Mounting Type	Contact Finish - Mating	Features	Connector Type	Primary Material	Termination
SWITCHCRAFT/CONXALL EN3C5MKX	5	250 VAC	Elastomer	Bayonet Lock	Black	7.5 A	General Purpose Instrumentation Marine Medical	Keyed	Copper Alloy	4.06 mm	0.265 in	0.16 "	6.73 mm	IP66 IP68	Thermoplastic	-40 C	65 °C	Unshielded	UL94 V-0	Free Hanging (In-Line)	Gold	Backshell Cable Clamp Coupling Nut	Plug Male Pins	Plastic
SWITCHCRAFT/CONXALL EN3C5MCLX	5	250 VAC	Elastomer	Bayonet Lock	Black	7.5 A	General Purpose Instrumentation Marine Medical	Keyed	Copper Alloy	5.84 mm	0.38 in	0.23 in	9.65 mm	IP66 IP68	Thermoplastic	-40 C	65 °C	Unshielded	UL94 V-0	Free Hanging (In-Line)	Gold	Backshell Cable Clamp Coupling Nut	Plug Male Pins	Plastic	Crimp
SWITCHCRAFT/CONXALL EN3C5MX	5	250 VAC	Elastomer	Bayonet Lock	Black	7.5 A	General Purpose Instrumentation Marine Medical	Keyed	Copper Alloy	4.06 mm	0.265 in	0.16 "	6.73 mm	IP66 IP68	Thermoplastic	-40 C	65 °C	Unshielded	UL94 V-0	Free Hanging (In-Line)	Gold	Backshell Cable Clamp Coupling Nut	Plug Male Pins	Plastic
SWITCHCRAFT/CONXALL EN3C5MCX	5	250 VAC	Elastomer	Bayonet Lock	Black	7.5 A	General Purpose Instrumentation Marine Medical	Keyed	Copper Alloy	4.06 mm	0.265 in	0.16 "	6.73 mm	IP66 IP68	Thermoplastic	-40 C	65 °C	Unshielded	UL94 V-0	Free Hanging (In-Line)	Gold	Backshell Cable Clamp Coupling Nut	Plug Male Pins	Plastic	Crimp
