FE Series

Catalog

FILM CAPACITORS 1100V 45UF ESR=4.2MOHMS 10% 4 PINS P2=20.3MM

Part	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Capacitance	Tolerance	ESR (Equivalent Series Resistance)	Applications	Package / Case	Lead Spacing	Lead Spacing	Dielectric Material	Termination	Height - Seated (Max) [Max]	Height - Seated (Max)	Features	Voltage Rating - DC	Voltage Rating - DC	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]
KYOCERA AVX FE52GI8L0456KB	125 °C	-40 C	Through Hole	45 µF	10 %	4.2 mOhm	DC Filtering DC Link	Radial - 4 Leads	52.5 mm	2.067 in	Polypropylene (PP) Metallized	PC Pins	2.591 in	65.8 mm	Low ESR	1100 V	1.1 kV	1.772 in	57.5 mm	2.264 in	45 mm
KYOCERA AVX FE52GF8C0506KB	125 °C	-40 C	Through Hole	50 µF	10 %	4.2 mOhm	DC Filtering DC Link	Radial - 4 Leads	52.5 mm	2.067 in	Polypropylene (PP) Metallized	PC Pins	2.394 in	60.8 mm	Low ESR	900 VDC			2.264 in		1.378 in	57.5 mm	35 mm
