Fixed Terminal Blocks SPT 2.5/ 7-H-5.0 5MM 7P HORZ SPR
Fixed Terminal Blocks SPT 2.5/ 7-H-5.0 5MM 7P HORZ SPR
| Part | Housing Material | Wire Termination | Number of Levels | Mating Orientation | Positions Per Level | Voltage | Current | Color | Pitch | Pitch | Mounting Type | Wire Gauge [Max] | Wire Gauge [Min] | Positions Per Level [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | 1 | Horizontal with Board | 12 | 300 VDC | 20 A | Green | 0.197 in | 5 mm | Through Hole | 24 AWG | 12 AWG | |
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | 1 | Vertical with Board | 5 | 300 VDC | 20 A | Green | 0.197 in | 5 mm | Through Hole | 24 AWG | 12 AWG | |
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | 1 | Horizontal with Board | 5 | 300 VDC | 10 A | Green | 0.138 " | 3.5 mm | Through Hole | 24 AWG | 16 AWG | |
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | 1 | Vertical with Board | 4 | 300 VDC | 10 A | Green | 0.138 " | 3.5 mm | Through Hole | 24 AWG | 16 AWG | |
 Phoenix Contact | Screwless - Spring Cage Tension Clamp | 1 | Vertical with Board | 6 | 300 VDC | 10 A | Green | 0.138 " | 3.5 mm | Through Hole | 24 AWG | 16 AWG | ||
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | 1 | Horizontal with Board | 300 VDC | 20 A | Green | 0.197 in | 5 mm | Through Hole | 24 AWG | 12 AWG | 7 | |
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | 1 | Horizontal with Board | 300 VDC | 10 A | Green | 0.138 " | 3.5 mm | Through Hole | 24 AWG | 16 AWG | 7 | |
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | 1 | Vertical with Board | 3 | 300 VDC | 20 A | Green | 0.197 in | 5 mm | Through Hole | 24 AWG | 12 AWG | |
 Phoenix Contact | Polyamide (PA) Nylon | Screwless - Spring Cage Tension Clamp | 1 | Horizontal with Board | 1 | 300 VDC | 20 A | Green | Through Hole | 24 AWG | 12 AWG |
