887-078 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 78POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Gender | Card Type | Color | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Pitch | Pitch | Contact Material | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Positions | Mounting Type | Termination | Read Out | Number of Positions/Bay/Row | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Non Specified - Dual Edge | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.96 mm | 0.156 in | Copper Alloy | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 78 | Through Hole | Solder | Dual | 39 | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Non Specified - Dual Edge | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.96 mm | 0.156 in | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 78 | Right Angle Through Hole | Solder | Dual | 39 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Non Specified - Dual Edge | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.96 mm | 0.156 in | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | 78 | Through Hole | Solder | Dual | 39 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Non Specified - Dual Edge | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.96 mm | 0.156 in | Copper Alloy | 78 | Through Hole | Solder | Dual | 39 | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Non Specified - Dual Edge | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.96 mm | 0.156 in | Copper Alloy | 78 | Board Edge Straddle Mount | Solder | Dual | 39 | Card Extender | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Non Specified - Dual Edge | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.96 mm | 0.156 in | Copper Alloy | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 78 | Through Hole | Solder | Dual | 39 | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Non Specified - Dual Edge | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.96 mm | 0.156 in | Copper Alloy | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | 78 | Board Edge Straddle Mount | Solder | Dual | 39 | Card Extender |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Non Specified - Dual Edge | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.96 mm | 0.156 in | Copper Alloy | 0.128 " | 3.25 mm | 78 | Board Edge Straddle Mount | Solder | Dual | 39 | Card Extender | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Non Specified - Dual Edge | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.96 mm | 0.156 in | Copper Alloy | 0.156 " | 3.96 mm | 78 | Through Hole | Solder | Dual | 39 | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Non Specified - Dual Edge | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | Cantilever | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.96 mm | 0.156 in | Copper Alloy | M3 Threaded Insert Top Mount Opening | 78 | Through Hole | Wire Wrap | Dual | 39 |
